Schneider Electric TeSys D Reversing Contactor 230V AC Coil, 3-Pole, 9A, 5.5 kW, 3 NO Contacts LC2D09U7V
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Reversing |
| Length | 77mm |
| Model | LC2D09U7V |
| Depth | 86mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | LC2D |
| Power Rating | 5.5kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | UL, CSA |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 240V |
| Contactor Application | Resistive Load, Motor Control |
| Pole and Throw Configuration | 3 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running |
| Example of use | all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Equipped with 3 normally open (NO) contacts for reliable switching.
- Power rating of 5.5 kW at 240V suitable for resistive and motor control loads.
- Includes two auxiliary contacts configured as 1 NO and 1 NC for added switching capabilities.
- Mount type is DIN Rail with IP20 finger-safe screw terminals offering secure installation.
- Operational temperature range from -5°C to 60°C for versatile industrial use.
- Pre-installed interlock ensures safety by allowing only one contactor to close at a time.
- Meets international standards including UL and CSA for compliance assurance.
- Designed for ease of installation with panel or DIN rail mounting options.
Product Description
Schneider Electric LC2D09U7V reversing contactor features a 230V AC coil and is engineered for motor control and resistive load applications. It is a 3-pole contactor with a continuous current rating of 9A and a power rating of 5.5 kW at 240V. The product incorporates three normally open (NO) contacts and comes preassembled with reversing power busbar, suitable for industrial automation and control gear environments.
The contactor includes two auxiliary contacts with configurations of 1 NO and 1 NC, enhancing switching capability within control circuits. Its DIN Rail mounting design and IP20 finger-safe screw terminals with both North American and international terminal markings allow for quick and safe installation across diverse industrial settings. Operable within a temperature range of -5°C to 60°C, this device is robust for various operational conditions.
Schneider Electric’s TeSys D series offers a linear translation movement that provides double breaking of the poles for reliable and effective operation. The built-in pre-installed mechanical interlock prevents simultaneous closure of contactors, enhancing operational safety during motor reversing operations.
Applicable in industrial sectors such as manufacturing, HVAC systems, automation lines, and motor-driven processes, this device meets international standards including UL and CSA for quality assurance. It supports utilization categories AC1 for resistive loads and AC3 for squirrel cage motors, making it versatile for equipment like conveyors, compressors, pumps, elevators, and mixers.
Equipped with 3 normally open contacts for reliable operation. Two auxiliary contacts for versatile control and signalling. DIN rail mounting and screw terminals for easy installation and secure connections. IP20 finger-safe protection ensures operator safety.
Designed for motor control, reversible functions, and resistive load applications. Wide operating temperature range supports various industrial environments. Complies with UL and CSA standards for international compatibility.
Designed for disassembly to support sustainability initiatives.
Schneider Electric’s LC2D09U7V contactor is a key component in automation and control systems, delivering dependable performance and ease of use. Explore more Contactors and control gear in the Automation & Control Gear category on EnvMart for comprehensive industrial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this model is 5.5 kW at 240V, suitable for resistive and motor control loads.
It operates within a temperature range of -5°C to 60°C, making it suitable for various industrial environments.
This unit is a 3-pole contactor, designed for effective motor control and switching applications.
It is designed for resistive loads and motor control, specifically suitable for applications like conveyors, compressors, and pumps.
The coil voltage for this reversing contactor is 230V AC, which is standard for many industrial applications.
This model includes two auxiliary contacts configured as 1 normally open (NO) and 1 normally closed (NC).
It is designed for DIN Rail mounting, which allows for easy and secure installation in various setups.
This unit meets international standards including UL and CSA, ensuring compliance for various applications.
The depth of this model is 86mm and the width is 90mm, making it compact for installation in control panels.
It features IP20 finger-safe screw terminals with both North American and international terminal markings for secure connections.
The maximum contact voltage for this reversing contactor is 690V AC, allowing for versatile application in various electrical systems.
The built-in mechanical interlock prevents simultaneous closure of contactors, enhancing operational safety during motor reversing operations.
