MEAN WELL IP65 Waterproof 1 Output LED Driver 48V 81.6W 1.7A Potentiometer

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP65 Waterproof 1 Output LED Driver 48V 81.6W 1.7A Potentiometer

Name: MEAN WELL IP65 Waterproof 1 Output LED Driver 48V 81.6W 1.7A Potentiometer
Brand: MEAN WELL
SKU: 361362
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP65
IP Rating	IP65
Mount Type	Screw
Series	HLG-80H
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	81.6W
Input Voltage	305, 90, 127, 431V ac
Output Voltage	48V
Power Dissipation	81.6W
Standards/Approvals	CB, CE, CSA, SELV, UL
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	738-2321 Brand: [MEAN WELL](https://in.rsdelivers.com/brands/mean-well)Manufacturers Part No.: HLG-80H-48A Distrelec Article No.: 30386971
Dimming Operation	Potentiometer
Primary Type	AC, DC
Driver Current	1.7A

Key Features

Universal AC input voltage range covers 90 to 431V AC for compatibility.
Built-in active PFC function improves power quality and efficiency.
Designed for IP65 rated indoor/outdoor use with waterproof enclosure.
Supports three in one dimming (1-10VDC, PWM, or resistance).
Provides protection against short circuit, overload, over voltage, and over temperature.
Compliance with global safety standards including CB, CE, CSA, SELV, and UL.
Ideal for LED lighting and moving sign applications in dry, damp, and wet locations.
Enclosed configuration enables robust, dust and rain resistant installation.

Product Description

MEAN WELL HLG-80H-48A is a durable, IP65 rated LED driver capable of supplying a single output of 48 volts DC with a maximum power of 81.6 watts and a current of 1.7 amps. It operates over a wide universal AC input voltage range from 90 to 431 volts, making it suitable for various electrical environments.

The driver is built with a waterproof enclosure meeting IP65 standards, allowing it to be installed safely in indoor or outdoor locations exposed to dust and water. Its enclosure utilizes a screw mount type for secure installation.

MEAN WELL’s built-in active power factor correction (PFC) enhances energy efficiency and reduces electrical noise. The device supports a three-in-one dimming function, which can be controlled via 1 to 10 V DC signals, PWM signals, or resistance adjustment through an internal potentiometer.

Protection mechanisms against short circuits, overload, over voltage, and over temperature ensure the reliability and longevity of the device under various operational conditions. It complies with international safety certifications, including CB, CE, CSA, SELV, and UL, and meets EMC standards such as EN55015 Class B and harmonic current standards EN61000-3-2 Class C.

This LED driver series is ideal for industrial and commercial LED lighting systems, including moving signage and other applications requiring constant voltage and current supply. It can be installed in dry, damp, or wet locations due to its robust design.

Universal AC input voltage from 90 to 431 V. IP65 waterproof enclosure suitable for harsh environments. Supports potentiometer based dimming operation. Active power factor correction for improved efficiency. Protection against short circuit, overload, over voltage, and temperature.

Compliance to multiple international safety and EMC standards. Enclosed design with screw mount configuration. Single output delivering 48 V at 1.7 A, 81.6 W power output. Suitable for LED lighting and signage applications.
