MEAN WELL IP67 5 Output Dimmable Constant Voltage LED Driver 20V 60W 3A 1 to 10 V PWM Resistance

MEAN WELL LPF-60D-20 is a high-performance, IP67 rated 5 output dimmable constant voltage LED driver delivering 20V output voltage at a maximum power of 60W with a rated current of 3A. This enclosed AC-DC power supply features a wide universal AC input voltage range from 90 to 305V AC, suitable for global applications. Its IP67 encapsulation makes it ideal for outdoor and harsh industrial environments where water and dust resistance are essential.

This LED driver offers a versatile 3 in 1 dimming function compatible with 1 to 10 Vdc control voltage, PWM signal, or resistance dimming, allowing flexible brightness control to meet diverse lighting system needs. The driver is built with full isolation and an enclosed plastic housing for safety, and it relies on free air convection for cooling, eliminating the need for fans and reducing maintenance requirements.

MEAN WELL LPF-60D-20 ensures robust protection features including short circuit, overload, over voltage, and over temperature safeguards to enhance operational reliability and prolong lifespan. With a high efficiency of up to 90% and built-in active power factor correction (PFC), the driver reduces energy consumption and improves power quality.

Certified to meet international standards such as UL8750, EN61347-1, EN61347-2-13, CE, CSA, ENEC, CB, and EAC, this LED driver complies with strict global safety and EMC requirements, making it a trustworthy choice for industrial, commercial, and signage lighting applications. The driver is designed especially for constant voltage LED lighting and moving sign usage, supporting the demanding needs of industrial plants, commercial facilities, and transportation projects.

Manufactured in China, the LPF-60D-20 model is part of MEAN WELL’s LPF-60D series known for waterproof construction and dimmable performance. The compact enclosure and screw mounting type facilitate easy and safe installation.

Fully encapsulated IP67 waterproof LED driver for outdoor use. Universal AC input voltage range from 90 to 305V AC. Multiple dimming options: 1 to 10 Vdc, PWM, resistance dimming. Comprehensive protective features for safe operation.

High efficiency and built-in active power factor correction. Robust compliance with worldwide safety and EMC standards. Enclosed plastic case with free air convection cooling. Suitable for industrial, commercial, and signage LED lighting.

Part of the LPF-60D series with proven quality and reliability.
