Schneider Electric Acti9 IC60N Miniature Circuit Breaker 2-Pole 1A Type C Thermal Magnetic Trip 100V-440V A9F74201

Schneider Electric A9F74201 Acti9 IC60N Miniature Circuit Breaker is a high-performance protective device designed for electrical distribution systems in industrial, commercial, and residential buildings. This 2-pole breaker with a rated current of 1 Amp features a thermal magnetic trip unit and Type C tripping characteristics, making it ideal for protecting circuits with inductive loads where switching surges are common.

The breaker supports AC voltages from 100V to 440V and DC voltages up to 144V, ensuring versatile application compatibility across a wide range of electrical networks, including TN and IT neutral systems. It conforms to international standards EN/IEC 60898-1 and EN/IEC 60947-2, ensuring reliability and safety compliance recognized globally.

The robust design includes insulated screw terminals rated IP20, ensuring operator safety with reduced risk of accidental electric contact. With compact dimensions (85 mm height, 36 mm width, 78.5 mm depth), it fits neatly into standard DIN rail mounting systems, allowing efficient use of panel space.

VisiSafe technology guarantees that the downstream circuit remains safe despite overvoltage conditions. The integrated VisiTrip red window provides instant visual indication of fault tripping, reducing troubleshooting time and minimizing downtimes. Double clip dismounting and compatibility with comb busbars facilitate flexible and rapid field installation and maintenance.

This Miniature Circuit Breaker is suitable for use in environments with high levels of electrical pollution and is actively used in controlling industrial automation circuits as well as commercial electrical boards. Its durable construction ensures long service life even under harsh conditions.

Equipped with thermal magnetic trip mechanism ensuring fast circuit disconnection. Rated current of 1 Amp with 2 protected poles for versatile electrical setups. Type C tripping curve suitable for high inductive loads and surges.

Compliant with IEC/EN 60898-1 and IEC/EN 60947-2 safety standards. DIN rail mounting with screw terminals enables secure installation. Compact design with dimensions 85 mm height, 36 mm width, and 78.5 mm depth. IP20 rated insulated terminals provide operator safety and prevent contact with live parts.

VisiTrip red fault indicator for fast troubleshooting and system management. Suitable for industrial and commercial electrical protection, especially in polluted environments. Country of origin: France confirming manufacturing quality and standards adherence.
