MEAN WELL IP67 Rated 1 Output LED Driver, 36V, 187.2 W, 5.2A, 1 to 10 V PWM Dimming

MEAN WELL HLG-185-36B is a high-efficiency, IP67 rated LED driver designed for reliable and stable LED lighting power delivery. It features a single 36 V output delivering up to 187.2 W power at 5.2 A current. This encapsulated power supply supports input voltages ranging from 90 V to 370 V AC, making it adaptable to various electrical environments.

The driver operates in constant voltage mode and supports 1 to 10 V PWM or resistance dimming, allowing smooth brightness control. Its robust encapsulation and IP67 waterproof rating enable use in dry, damp, or wet indoor/outdoor settings, ideal for LED lighting installations and moving signs.

Safety and reliability are assured with built-in protections against short circuit, overload, over voltage, and over temperature conditions. The unit meets international standards including UL8750, EN61347-1/-2-13, UL60950-1, and TUV EN60950-1, ensuring compliance and performance.

This LED driver is specifically designed with power factor correction (PFC) compliant with EN 61000-3-2 to reduce harmonic current emissions. The product includes 300 mm un-terminated input and output wiring leads (18 AWG and 14 AWG respectively) and a 300 mm dimming lead to facilitate installation flexibility.

Typical industrial, commercial, and residential applications include LED signage, architectural lighting, and general purpose LED lighting systems requiring reliable dimmable power solutions under harsh environmental conditions.

The driver is encapsulated with an IP67 rating, ensuring waterproof protection for indoor and outdoor applications. Supports input voltages of 90 V to 370 V AC, suitable for various power supply environments. Features constant voltage output mode for stable LED power supply.

Includes multiple protections such as short circuit, overload, over voltage, and over temperature safeguards. Complies with UL, CE, EN, and TUV safety and electromagnetic compatibility standards. Equipped with power factor correction in compliance with EN 61000-3-2 standards.

Adjustable output current through 1 - 10 V PWM or resistance dimming input. Designed for high efficiency, long life, and reliability in LED lighting and moving sign applications. Encapsulated construction allows use in dry, damp, or wet environments.

Comes with un-terminated input, output, and dimming leads for flexible wiring options. Explore MEAN WELL LED drivers and related LED lighting components at EnvMart for industrial and commercial lighting solutions.
