MEAN WELL IP67 1 Output LED Driver 12V 156W 13A 1 to 10V PWM Resistance

MEAN WELL HLG-185H-12B is a high-performance LED Driver designed for powering LED lighting with a robust IP67 rated encapsulated panel mount enclosure. Delivering a constant voltage output of 12V at a maximum of 156W and a driver current of 13A, this driver ensures reliable and efficient operation across a wide input voltage range of 90V to 370V AC.

Engineered for industrial and commercial LED lighting applications, it supports 1 to 10V PWM resistance dimming, allowing smooth brightness control in lighting systems. The design incorporates extensive protection features including over current, short circuit, overload, over voltage, and over temperature safeguards, enhancing durability and safety in harsh conditions.

This LED driver complies with international standards including CE, EN, TUV, and UL, making it suitable for deployment in diverse environments such as dry, damp, or wet indoor and outdoor locations. Its encapsulated configuration provides high reliability and long operational life.

The product includes a 300mm un-terminated 3-core 18AWG input lead, 300mm un-terminated 2-core 14AWG output lead, and a 300mm un-terminated 2-core 18AWG dimming lead, facilitating flexible installation. EMC compliance to EN 55022 Class B and power factor correction according to EN 61000-3-2 ensure minimal electromagnetic interference and optimized energy usage.

Typical industrial uses encompass LED lighting installations, moving signs, and various lighting control systems in manufacturing plants, commercial buildings, and outdoor signage applications.

Encapsulated panel mount design ensures robust protection and easy integration. Supports input voltage ranges of 90, 127, 264, and 370V AC for versatile operation. Constant voltage operating mode with high efficiency and long service life.

Equipped with multiple protections including over current, short circuit, overload, over voltage, and over temperature. Compliance with CE, EN, TUV, UL safety standards for global market suitability. Suitable for dry, damp, or wet locations including outdoor environments.

Adjustable constant current via output cable using 1-10V DC or 10V PWM signal or resistor. EMC compliance to EN 55022 Class B and power factor correction per EN 61000-3-2. Explore a wide range of LED drivers and electronic components in the Electronics & Electricals category on EnvMart for reliable and efficient lighting solutions.
