Celduc SOM Series Solid State Relay 60A Load DIN Rail Mount 40V dc Load 32V dc Control SOM06075

Celduc SOM06075 solid state relay is engineered for industrial and automation applications requiring reliable DC voltage switching. Rated for a maximum load current of 60A and load voltage up to 40 V dc, this DIN rail mount relay employs MOSFET technology to enable efficient switching with very low on-state resistance of 16mΩ, minimizing power loss and heat generation.

The relay features a screw terminal connection and SPST contact configuration suitable for various control circuit designs. Its zero cross switching function reduces electrical noise, making it ideal for sensitive electronic environments. Operating temperature range from -40°C to 90°C ensures durability under harsh conditions.

Protection index IP20 ensures the device is protected against solid objects larger than 12 mm while facilitating ventilation. The compact dimensions (45 mm length × 44.8 mm width × 30 mm height) allow for easy integration in electrical panels. With an off state leakage current of only 1 mA, the relay minimizes power consumption when inactive.

Certified by multiple international standards including VDE, UKCA, RoHS, EAC, cURus, CSA, and CE, the Celduc SOM06075 offers assured quality and performance reliability. The unit’s input control voltage ranges from 3.5 V dc minimum to 32 V dc maximum, providing flexible control options.

Utilizes MOSFET technology for efficient DC switching. Very low on-state resistance minimizes energy loss. Screw terminal type for secure wiring connections. SPST contact configuration for single-pole, single-throw switching.

Zero cross switching function reduces electrical noise. Wide operating temperature from -40°C to 90°C. IP20 protection rating suitable for electrical enclosures. Compact size for DIN rail installation. Compliance with VDE, UKCA, RoHS, EAC, cURus, CSA, and CE standards.

Low off state leakage current of 1 mA. Flexible input control voltage range of 3.5 to 32 V dc.

This solid state relay is suitable for use in industrial automation, manufacturing control systems, HVAC controls, and other applications requiring robust, fast switching DC control without mechanical wear. Its compact DIN rail mount design facilitates easy integration in electrical cabinets and control panels.
