STMicroelectronics 16 kB 70 ns Parallel Interface 24-Pin PCDIP NVRAM M48Z12-70PC1

STMicroelectronics M48Z12-70PC1 is a high-performance 16 kB non-volatile RAM (NVRAM) memory chip optimized for low power and fast access. It incorporates ZEROPOWER® technology combining static RAM with a lithium battery to maintain data integrity during power failures.

This 24-pin PCDIP packaged device has an 8-bit data bus width arranged as 2K x 8 bit organization. With a maximum random access time of 70 ns and parallel interface, it suits applications requiring rapid memory read/write operations.

The memory chip is designed for through-hole mounting and operates reliably within an industrial temperature range from 0°C to 70°C. Its supply voltage rating is between 4.5 V and 5.5 V with a nominal supply current of 80 mA.

Physical dimensions measure 34.8 mm in length, 18.34 mm in width, and 8.89 mm in height, allowing compact integration on printed circuit boards. The device does not have any certifications related to automotive standards.

This NVRAM is ideal for embedded systems, industrial electronics, automotive controls, telecommunications, and instrumentation requiring non-volatile data storage with fast access times and stable supply current.

This NVRAM features a 16 kB memory size organized as 2K x 8 bit. It uses a parallel interface and comes in a 24-pin PCDIP package for through-hole mounting. Operating temperature ranges from 0°C to 70°C for reliable industrial applications.

Minimum supply voltage is 4.5 V and maximum 5.5 V, with supply current of 80 mA. Compact dimensions of 34.8 mm length, 18.34 mm width, and 8.89 mm height facilitate PCB space optimization. ZeroPower technology integrates SRAM with a lithium battery for long-life non-volatility.

Designed for use in embedded systems, industrial controls, and other electronics requiring data retention. Explore more in the Semiconductor and Memory Chips categories at EnvMart for advanced electronic components.
