Omron Surface Mount Signal Relay 5V DC Coil, 1A Switching Current, DPDT Contact Configuration G6J-2FS-Y DC5

Name: Omron Surface Mount Signal Relay 5V DC Coil, 1A Switching Current, DPDT Contact Configuration G6J-2FS-Y DC5
Brand: Omron
SKU: 349803
Price: 2.98 USD
Availability: InStock



Category Signal Relay Brand Omron Condition New

Specifications

Country of Origin	China
Brand	Omron
Height	9mm
Length	10.6mm
Model	G6J-2FS-Y DC5
Width	5.7mm
Mount Type	Surface
Contact Material	Gold Plated
Series	G6J
Maximum Operating Temperature	85°C
Contact Configuration	DPDT
Minimum Operating Temperature	-40°C
Switching Current	1A
Terminal type	Surface Mount
Standards/Approvals	RoHS
Coil Resistance	173Ω
Coil Voltage	5V dc
Switching DC Voltage	110V dc
Switching AC Voltage	125V ac
Coil Power	140mW

Key Features

The relay features a compact design measuring 5.7mm width, 10.6mm length, and 9mm height.
Supports switching AC voltage up to 125V AC and DC voltage up to 110V DC.
Fully sealed construction ensures durability and reliable performance in industrial environments.
Gold plated contacts enhance conductivity and reduce contact resistance for optimal signal integrity.
Coil resistance is 173 ohms with coil power consumption of 140mW for efficient operation.
Operating temperature range from -40°C to 85°C suits a variety of demanding applications.
Surface mount type with terminals designed for easy installation on PCBs.
Complies with RoHS standards and approved by UL and CSA for safety and quality assurance.

Product Description

Omron G6J-2FS-Y DC5 Surface Mount Signal Relay offers a compact and durable solution for controlling signals and switch operations in electrical and automation systems. It incorporates a 5V DC coil with a double-pole double-throw (DPDT) contact configuration rated for 1 ampere switching current, providing versatile switching capabilities.

This relay is fully sealed to safeguard against environmental factors, ensuring long-term reliability in industrial and commercial applications. It features gold plated contacts to improve conductivity and reduce wear, thereby enhancing signal integrity and device longevity.

With its surface mount design and compact 5.7mm by 10.6mm footprint, this relay is ideal for space-constrained circuit board layouts. The coil resistance of 173 ohms and power consumption of 140mW demonstrate efficient electrical characteristics.

Operating temperatures range from -40°C to 85°C, making the relay suitable for a wide array of harsh environmental conditions. The product meets RoHS compliance along with UL and CSA approvals, affirming its quality and safety for use in North American industrial standards.

The relay meets FCC Part 68 requirements, featuring impulse withstand voltages of 1500V for 10x160μs between coil and contacts and between contacts of the same polarity, thus enhancing its durability in signal conditioning and communication applications.

The relay's compactness and high-performance switching make it suitable for automation equipment, electrical panels, HVAC control systems, telecommunications, manufacturing control circuits, and other industrial applications.

Surface mounting style facilitates integration into automated PCB assembly lines and high-density electronic designs. Gold plated contact material is ideal for low-level signal switching, preventing oxidation and contact degradation.

Its conforming to international safety and environmental standards ensures dependable operation and regulatory compliance globally. Commonly used in signal relay roles requiring ultra-compact size and high reliability.

This product is supplied new and originates from China. It is part of the Omron G6J series known for ultra-compact, highly reliable signal relays designed for modern electronics and industrial automation.

Explore more products in the Signal Relay category at EnvMart to find compatible components and automation solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model features a double-pole double-throw (DPDT) contact configuration, allowing for versatile switching capabilities in various applications.

It supports switching AC voltage up to 125V AC and DC voltage up to 110V DC, making it suitable for a range of electrical applications.

The relay has a compact design with dimensions of 5.7mm in width, 10.6mm in length, and 9mm in height, ideal for space-constrained layouts.

It operates with a 5V DC coil and has a power consumption of 140mW, ensuring efficient operation.

The operating temperature range is from -40°C to 85°C, which allows it to function effectively in harsh environmental conditions.

This unit features a surface mount design, which facilitates easy installation on printed circuit boards (PCBs).

The coil resistance is 173 ohms, which contributes to its efficient electrical characteristics.

It features gold plated contacts, which enhance conductivity and reduce contact resistance for optimal signal integrity.

The relay complies with RoHS standards and is approved by UL and CSA, ensuring safety and quality assurance for industrial applications.

This relay is commonly used in automation equipment, electrical panels, HVAC control systems, and telecommunications, among other industrial applications.

It features impulse withstand voltages of 1500V for 10x160μs between coil and contacts, enhancing its durability in signal conditioning applications.

This model is part of the Omron G6J series, known for its ultra-compact and highly reliable signal relays designed for modern electronics and industrial automation.
