Entrelec SNK Series Fused DIN Rail Terminal Block Grey 1-Level Fused Screw 1SNK508411R0000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Entrelec |
| Colour | Grey |
| Model | 1SNK508411R0000 |
| Series | SNK |
| Termination Type | Screw |
| Maximum Operating Temperature | 110°C |
| Number of Levels | 1 |
| Minimum Operating Temperature | -55°C |
| Pitch | 8mm |
| Standards/Approvals | RINA, EAC, DNV, cUL, CSA, CE, CB, Bureau Veritas |
| Minimum Wire Size AWG | 14AWG |
| Maximum Wire Size AWG | 12AWG |
| Cable CSA | 1.5, 4mm² |
| Terminal Block Current | 6.3A |
Key Features
- Constructed with rigid flame retardant material ensuring durability and safety.
- Fits 5x20mm or 5x25mm fuses accommodating various fuse sizes.
- Designed with two central jumper channels for efficient common distribution.
- Features an 8mm pitch and supports wire sizes from 1.5 to 4 mm² (AWG14 to AWG12).
- Rated for a maximum terminal block current of 6.3A and voltage of 250V.
- Operates safely within a temperature range from -55°C to 110°C.
- Unique asymmetrical profile prevents reverse mounting and aids visibility from all angles.
- Easy to install with positive snap action on standard ‘top hat’ DIN rails.
Product Description
Entrelec 1SNK508411R0000 is a high-quality SNK Series Fused DIN Rail Terminal Block engineered for robust electrical distribution in industrial and commercial applications. It offers secure screw clamp connections combined with one-level fuse protection, enhancing circuit safety and reliability.
This terminal block is built from rigid flame retardant grey material, ensuring resistance to harsh environments and electrical safety. It features a compact design with a reduced width compared to the previous Entrelec 5000 series, facilitating space-saving installations.
Equipped with two central jumper channels, the product simplifies common circuit distribution. It accommodates 5x20mm and 5x25mm fuses, catering to different fuse requirements. With an 8mm pitch and wire size capability from 1.5 to 4 mm² (AWG14 to AWG12), it supports current ratings of up to 6.3A at 250 volts.
The terminal block is designed for mounting on ‘top hat’ DIN rails using a unique asymmetrical profile that prevents reverse mounting errors and allows clear visibility from any direction. The positive snap action makes installation quick and efficient.
It is suitable for various environments with operating temperatures ranging from -55°C to 110°C. This device complies with an extensive list of international approvals including UL, CSA, CE, ATEX, IECex, RINA, EAC, DNV, CB, and Bureau Veritas, ensuring its applicability in demanding industrial, manufacturing, and electrical distribution systems globally.
Constructed from rigid flame retardant material for enhanced safety. Accommodates 5x20mm and 5x25mm fuse sizes for flexible fuse protection. Two central jumper channels simplify common distribution wiring. Compact 8mm pitch design reduces panel space requirements.
Rated for 6.3A current and 250V voltage capacity. Wide operating temperature range from -55°C to 110°C for reliable performance. Unique asymmetrical DIN rail mounting prevents reverse installation. Quick snap-fit installation on standard top hat DIN rails.
Compliant with UL, CSA, CE, ATEX, IECex, RINA, EAC, DNV, CB, and Bureau Veritas standards.
This fused DIN rail terminal block is ideal for industrial wiring, electrical panels, automation systems, and electrical distribution networks where safety and reliability are paramount.
Explore more DIN Rail Terminal Blocks and related products on EnvMart for your industrial and commercial electrical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum terminal block current rating is 6.3A.
It is rated for a maximum voltage of 250V.
This terminal block operates safely within a temperature range from -55°C to 110°C.
It supports wire sizes from 1.5 to 4 mm², which corresponds to AWG14 to AWG12.
It accommodates 5x20mm and 5x25mm fuses, allowing for flexible fuse protection.
The pitch of this model is 8mm, facilitating compact installations.
It is constructed from rigid flame retardant grey material, ensuring safety in various environments.
It complies with UL, CSA, CE, ATEX, IECex, RINA, EAC, DNV, CB, and Bureau Veritas standards.
The termination type is screw, providing secure connections for wiring.
This model is a one-level terminal block, designed for efficient circuit management.
The country of origin for this terminal block is India.
