RS PRO Push Button Switch Momentary Panel Mount SPST Blue LED IP67 13.6 mm Cutout 36 V dc 50 V ac 209-9069
Specifications
| Country of Origin | China |
|---|---|
| Brand | RS PRO |
| Model | 209-9069 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | RS PRO |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Switch Configuration | SPST |
| Minimum Operating Temperature | -35°C |
| Panel Cutout Size | 13.6 mm |
| Terminal type | Solder |
| Standards/Approvals | RS |
| LED Colour | Blue |
| Switch Operation | Momentary |
| Actuator Colour | Blue |
| Contact DC Voltage | 36V dc |
| Actuator Style | Flat |
| Switch Contact Current | 125mA |
| Contact AC Voltage | 50V ac |
Key Features
- The switch has a Single-Pole Single-Throw (SPST) contact configuration ensuring simple on/off control.
- It offers IP67 rating for protection against dust and water ingress, suitable for rugged environments.
- The actuator style is flat with a durable polyamide 6/6 build and a blue colored actuator.
- Suitable operating voltage is up to 36 V dc and 50 V ac with a contact current rating of 125 mA.
- The mechanical life expectancy is approximately 1,000,000 cycles ensuring long-term reliability.
- Operating temperature range spans from -35°C to 85°C for varied industrial applications.
- Panel mounting is facilitated by a threaded bushing with M12 x 0.75 thread specification.
- Terminal type is designed for solder connection ensuring secure electrical contact.
Product Description
RS PRO 209-9069 is a momentary push button switch designed for panel mounting applications with a precise 13.6 mm cutout size. The switch incorporates a bright blue LED indicator for visual confirmation, making it ideal for control panels where operator feedback is essential. Featuring a Single-Pole Single-Throw (SPST) configuration, it controls one single circuit with a momentary ON operation.
Manufactured with a robust polyamide 6/6 housing and a flat actuator style, this switch offers superior durability and tactile response. The IP67 rating certifies its protection against ingress of dust and immersion in water, allowing use in harsh industrial environments and outdoor applications.
The RS PRO 209-9069 push button switch supports operation within a temperature range of -35°C to 85°C and accommodates up to 36 V dc or 50 V ac voltages, suitable for diverse electrical and electronic control systems. Its contact current rating is 125 mA with gold over silver contacts to ensure low resistance and reliable switching cycles up to one million mechanical operations.
Panel mount installation is simplified via its threaded bushing with standard M12 x 0.75 threading, offering secure assembly and a clean aesthetic on control panels. The solder terminal type ensures strong electrical connections essential for signal integrity in electronic circuits.
The switch's momentary action is suitable for applications requiring temporary on signals or reset triggers. Its blue LED illumination enhances visibility in low light or high usage environments. The robust IP67 enclosure enables protection against dust and moisture environments.
Wide temperature tolerance supports use in both cold storage and heated industrial sites. Applications include test equipment, telecommunications hardware, networking devices, and handheld appliances. Made in China with quality assurance under the RS PRO brand.
RS PRO products are built to provide reliable performance with tested compliance to industry standards suitable for electrical, automation, and control systems. Explore more push button switch solutions and accessories in EnvMart's specialized electronic components category for full system integration and maintenance needs.
Explore more products in our Push Button Switches category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a Single-Pole Single-Throw (SPST) contact configuration, allowing for simple on/off control.
The maximum operating temperature for this switch is 85°C, making it suitable for various industrial applications.
It has an IP67 rating, providing protection against dust and immersion in water, suitable for harsh environments.
The required panel cutout size for this switch is 13.6 mm.
The contact current rating is 125 mA, ensuring reliable operation within specified electrical parameters.
It uses a solder terminal type, which ensures secure electrical connections essential for signal integrity.
This unit supports a contact DC voltage of up to 36 V and an AC voltage of up to 50 V.
The actuator style is flat, designed for a tactile response and ease of use.
The minimum operating temperature is -35°C, allowing for use in cold environments.
It is suitable for applications including test equipment, telecommunications hardware, networking devices, and handheld appliances.
The mechanical life expectancy is approximately 1,000,000 cycles, ensuring long-term reliability.
The country of origin for this push button switch is China.
