Celduc SO7 Series Solid State Relay 125 A Load 510 V Load DIN Rail Mount SO769090

Celduc SO7 Series Solid State Relay model SO769090 is engineered for high performance in controlling highly inductive single-phase AC loads and motors. Rated for a maximum load current of 125 A and a load voltage capacity of up to 510 V, this relay offers reliable switching with a zero-cross switching function to enhance efficiency and reduce electromagnetic interference.

The relay supports a wide control voltage range from 3 V up to 32 V DC with regulated control current, making it adaptable to various control systems. It includes voltage protection devices such as transil on the input and RC + VDR on the output side, ensuring robust immunity against electrical interference.

The device features a green LED input indicator to display operational status clearly. Its compact dimensions (59.4 mm length, 44.8 mm width, and 30 mm height) and DIN rail mounting type facilitate easy installation in industrial enclosures.

Designed to operate reliably within temperatures as low as -55°C up to 100°C, it requires mounting on a heatsink due to its high current handling capability. The relay is constructed with screw terminal types for secure electrical connections and conforms to multiple standards including CE, CSA, cURus, EAC, RoHS, VDE, and UKCA.

This solid state relay is ideal for applications in industrial automation, HVAC systems, manufacturing controls, and electrical power equipment where high switching reliability and noise reduction are critical.

Suitable for controlling highly inductive loads and phase angle regulator applications. Wide control voltage range with regulated control current for flexibility. Robust voltage protection ensures high immunity to interference.

Compact DIN rail mount design with screw terminals for easy installation. Operational temperature range from -55°C to 100°C. Complies with international standards CE, CSA, cURus, EAC, RoHS, VDE, and UKCA. Includes a green LED input indicator for clear operational status display.

Designed for industrial, automation, HVAC, and manufacturing applications requiring reliable solid state switching. Explore more industrial electrical components and Solid State Relays at EnvMart for your automation and control needs.
