Hongfa Europe GMBH PCB Power Relay 5V dc Coil 10A Switching Current DPDT HF140FF/005-2ZTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.3mm |
| Length | 29mm |
| Model | HF140FF/005-2ZTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF140FF |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 47Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 530mW |
Key Features
- High power switching capability of up to 240W for DC applications.
- Compact PCB mount relay with dimensions 29mm length, 26.3mm height, and 13mm width.
- Durable silver alloy contacts designed for long life and reliability.
- Operating temperature range from -40°C to 85°C suitable for varied environments.
- Isolation voltage of 5KVAC provides excellent coil-to-contact isolation.
- Low coil power consumption of 530mW ensures energy efficiency.
- Equipped with PCB pin terminals for secure mounting on circuit boards.
- Contact resistance as low as 50mΩ enhances switching performance.
Product Description
Hongfa Europe GMBH HF140FF/005-2ZTF is a PCB mount power relay featuring a 5V dc coil and 10A switching current in a DPDT contact configuration. Its compact form factor of 29mm length, 26.3mm height, and 13mm width makes it suitable for space-constrained electronic assemblies.
This relay uses durable silver alloy contacts to ensure reliable high power switching of up to 240W DC, with excellent contact resistance of 50mΩ to minimize losses. The device supports switching voltages up to 30V DC and 250V AC, making it versatile for a wide range of power relay applications.
Operating temperature ranges from -40°C to 85°C, allowing usage in harsh industrial and automotive environments. It features robust isolation voltage of 5KVAC between coil and contacts, providing safety and preventing interference.
Designed for PCB mounting, it uses PCB pin type terminals and operates with a low coil power consumption of 530mW, optimizing energy efficiency. The relay is RoHS compliant, demonstrating adherence to environmental standards.
Common applications include control devices in industrial automation, electronic circuits, and automotive industry systems where reliable power switching is critical. Its flux-proof type design enhances durability and operational lifespan, rated up to 10 million cycles.
High power switching up to 240W DC. Compact PCB mount design dimensions: 29mm length, 26.3mm height, 13mm width. Silver alloy contacts for durability and efficiency. Wide operating temperature range from -40°C to 85°C. 5KVAC coil to contact isolation voltage.
Low coil power consumption of 530mW. PCB pin terminals for secure mounting. Contact resistance of 50mΩ for low loss switching. RoHS compliant environmental friendly design. Ideal for industrial, electronic automation, and automotive applications.
Explore more Power Relays from Hongfa Europe GMBH and other reliable brands at EnvMart, your source for professional-grade electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a switching current rating of 10A, making it suitable for various power relay applications.
The relay measures 29mm in length, 26.3mm in height, and 13mm in width, allowing for compact PCB mounting.
It operates with a coil voltage of 5V DC, which is standard for many electronic applications.
The relay supports a maximum switching voltage of 30V DC and 250V AC, making it versatile for different applications.
This unit features a DPDT (Double Pole Double Throw) contact configuration, providing flexibility in circuit design.
It can operate in temperatures ranging from -40°C to 85°C, suitable for harsh environments.
The contact resistance is as low as 50mΩ, enhancing switching performance and minimizing losses.
The contacts are made from durable silver alloy, designed for long life and reliability in high power switching applications.
The coil power consumption is 530mW, contributing to energy efficiency in operation.
It is equipped with PCB pin terminals, ensuring secure mounting on circuit boards for reliable connections.
Yes, it is RoHS compliant, indicating adherence to environmental standards regarding hazardous substances.
Common applications include control devices in industrial automation, electronic circuits, and automotive systems where reliable power switching is critical.
