Phoenix Contact Pluggable Terminal Block 4-Contact, 5.08 mm Pitch, 1 Row, Straight Orientation, Push-in Spring 1777824

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact Pluggable Terminal Block 4-Contact, 5.08 mm Pitch, 1 Row, Straight Orientation, Push-in Spring 1777824

Name: Phoenix Contact Pluggable Terminal Block 4-Contact, 5.08 mm Pitch, 1 Row, Straight Orientation, Push-in Spring 1777824
Brand: PHOENIX CONTACT
SKU: 333188
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Germany
Voltage	630V
Brand	Phoenix Contact
Colour	Green
Orientation	Straight
Current	12A
Length	27.2mm
Model	1777824
Depth	15mm
Width	30.12mm
Housing Material	Polyamide
Series	FRONT-MSTB 2.5/4-STF-5.08
Number of Rows	1
Pitch	5.08mm
Number of Contacts	4
Connector Gender	Female
Minimum Wire Size mm²	0.34mm²
Maximum Wire Size mm²	2.5mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	12AWG
Wire Connection Method	Push-in Spring
PCB connector, nominal current	12 A, rated voltage (III/2): 320 V, number of positions: 4, pitch: 5.08 mm, connection method: Front screw connection, colour: green, contact surface: Tin

Key Features

Features a single row configuration with straight orientation.
Uses push-in spring wire connection for reliable electrical contact.
Supports nominal current up to 12 A and voltage rating of 630 V.
Accommodates wire sizes from 0.34 mm² to 2.5 mm² or AWG 24 to 12.
Constructed with green polyamide housing and tin-plated contact surfaces.
Suitable for industrial PCB applications requiring pluggable connectors.
Manufactured in Germany, ensuring high quality and reliability.

Product Description

Phoenix Contact 1777824 is a high-quality pluggable terminal block designed for PCB connections in industrial and commercial electronics. Featuring 4 contacts in a single row, it provides a pitch of 5.08 mm, which is a common spacing standard for reliable connectivity.

The terminal block uses a straight orientation and a push-in spring wire connection method, enabling fast and secure wire attachment without screws. It supports a nominal current of 12 A and is rated for voltages up to 630 V, making it suitable for various power electronics and automation systems.

The housing is made from durable green polyamide material, while the contact surfaces are tin-plated for corrosion resistance and excellent conductivity. Wire size compatibility ranges from 0.34 mm² (24 AWG) to 2.5 mm² (12 AWG), accommodating a variety of wiring needs.

Compact dimensions (length 27.2 mm, width 30.12 mm, depth 15 mm) allow for efficient PCB space utilization. This product is manufactured in Germany, reflecting stringent quality standards for industrial components.

Single row, 4-contact pluggable terminal block. 5.08 mm pitch and straight orientation. Push-in spring wire connection for easy installation. Supports currents up to 12 A and voltages up to 630 V. Green polyamide housing with tin-plated contacts.

Compatible with wire sizes 0.34 mm² to 2.5 mm² (24 to 12 AWG). Manufactured in Germany for reliable performance.

This terminal block is ideal for electronic components, power connectors, and automation applications where secure and maintainable wiring solutions are essential. Explore more components and connectivity solutions in the Electronics Components category on EnvMart.
