TE Connectivity Buchanan Series Pluggable Terminal Block 9-Contact 5.08 mm Pitch 1 Row 300V AC 15A 796634-9

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Buchanan Series Pluggable Terminal Block 9-Contact 5.08 mm Pitch 1 Row 300V AC 15A 796634-9

Name: TE Connectivity Buchanan Series Pluggable Terminal Block 9-Contact 5.08 mm Pitch 1 Row 300V AC 15A 796634-9
Brand: TE Connectivity
SKU: 328497
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	300V ac
Brand	TE Connectivity
Colour	Green
Orientation	Right Angle
Current	15A
Length	10.16mm
Model	796634-9
Depth	18.4mm
Width	15.5mm
Housing Material	Polyamide
Series	Buchanan
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	RoHS, UL no E 60677, CSA File no 007189A
Number of Contacts	9
Connector Gender	Male
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	3mm²
Minimum Wire Size AWG	12AWG
Maximum Wire Size AWG	30AWG
Wire Connection Method	Screw

Key Features

Constructed with durable green polyamide housing for long-lasting use.
Supports wire sizes from 30 AWG to 12 AWG with screw connection method.
Right angle orientation enables space-efficient PCB mounting.
Rated for 15A current and 300V AC voltage for robust performance.
Side stackable design allows flexible assembly options.
Complies with RoHS standards and UL and CSA approvals for safety and reliability.
Measures 15.5 mm width, 18.4 mm depth, and 10.16 mm length for compact installation.

Product Description

TE Connectivity model 796634-9 is a Buchanan Series pluggable terminal block designed for electronic and electrical applications needing secure and modular wire connections. Featuring 9 contacts arranged in a single row with a 5.08 mm pitch, this right angle terminal block is fabricated using green polyamide 6.6 GF housing, ensuring durability and resistance in demanding environments.

This terminal block supports a wide wire gauge range from 30 AWG to 12 AWG (0.05 mm² to 3 mm²) and utilizes M3 screw type terminals for secure and easy wire connection, reducing assembly time with its rising clamp design. The side entry terminals allow for a compact and flexible mechanical integration into PCB designs.

The component operates safely at 15A current and 300V AC voltage, suitable for varied industrial, automation, and manufacturing applications. It meets RoHS compliance and is UL recognized (E 60677) and CSA filed (007189A), ensuring adherence to industry safety and environmental standards.

Compact dimensions of 15.5 mm width, 18.4 mm depth, and 10.16 mm length provide a space-saving solution for circuit boards and control panels. The terminal block is side stackable and designed for right angle PCB mounting, enhancing design versatility in electronic assemblies.

This product is ideal for use in industrial automation systems, power connectors, electronics components manufacturing, and electronic control devices where reliable and maintainable electrical connections are required.

Constructed with durable green polyamide housing for long-lasting use. Supports wire sizes from 30 AWG to 12 AWG with screw connection method. Right angle orientation enables space-efficient PCB mounting. Rated for 15A current and 300V AC voltage for robust performance.

Side stackable design allows flexible assembly options. Complies with RoHS standards and UL and CSA approvals for safety and reliability. Measures 15.5 mm width, 18.4 mm depth, and 10.16 mm length for compact installation.
