Honeywell Technologies Gauge Pressure Sensor Through Hole DIP 8-Pin SSCDANN060PG3A5
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 60 psi |
| Height | 13.75mm |
| Length | 10mm |
| Model | SSCDANN060PG3A5 |
| Sensor Type | Gauge Pressure Sensor |
| Mount Type | Through Hole |
| Series | SSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Single Axial Barbed |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 0psi |
| Maximum Overload Pressure | 120psi |
Key Features
- Measures gauge pressure from 0 psi to 60 psi with ±0.25% accuracy.
- Supports overload pressures up to 120 psi for pressure spike protection.
- Operates reliably in temperature ranges from -40°C to 85°C.
- Features single axial barbed port for easy tubing connection.
- Suitable for pneumatic pressure monitoring and portable test equipment.
- Compact size with length 10 mm and height 13.75 mm for PCB integration.
- Compatible with analogue or ADC front ends requiring low voltage supply.
Product Description
Honeywell Technologies SSCDANN060PG3A5 Gauge Pressure Sensor is a precision sensor measuring positive pressures relative to ambient atmosphere. Designed for through-hole DIP mounting with 8 pins, it provides accurate electronic measurement within industrial, laboratory, and HVAC applications.
Operating from a low-voltage supply range of 3.3V to 5V, it suits control panels and portable test equipment where compact and reliable pressure sensing is needed. Its single axial barbed port allows easy connection to fluid handling or pneumatic assemblies.
The sensor measures gauge pressures from 0 to 60 psi with an accuracy of ±0.25%, accommodating measurement tasks requiring narrow tolerances. It can safely handle transient overload pressures up to 120 psi, protecting against pressure spikes encountered in dynamic systems.
This device performs well across a wide temperature range of -40°C to 85°C, enabling its use in harsh industrial environments and environmental test chambers. The mechanical package size of 10 mm length and 13.75 mm height provides effective PCB space utilization in electronic instrumentation.
Measures gauge pressure 0-60 psi with ±0.25% accuracy. Overload pressure tolerance up to 120 psi. Wide operating temperature from -40°C to 85°C. Through-hole mounting in 8-pin DIP package. Single axial barbed port for media connection.
Operates from 3.3V to 5V supply voltage. Compact dimensions for PCB integration.
Ideal for industrial pneumatic control panels, portable testing devices, HVAC monitoring, fluid handling systems, and environmental chambers requiring consistent pressure measurement. This sensor’s robust design and precision make it a trusted component for electronic pressure monitoring solutions.
Explore additional Honeywell Pressure Sensors and related electronic components in the Sensors category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It measures gauge pressure from 0 psi to 60 psi.
The accuracy of this sensor is ±0.25%.
It can safely handle transient overload pressures up to 120 psi.
This sensor operates reliably in temperature ranges from -40°C to 85°C.
It features through-hole mounting in an 8-pin DIP package.
It operates from a low-voltage supply range of 3.3V to 5V.
The sensor has a length of 10 mm and a height of 13.75 mm.
It features a single axial barbed port for easy tubing connection.
It is suitable for pneumatic pressure monitoring, portable test equipment, and HVAC applications.
The model number is SSCDANN060PG3A5.
It belongs to the SSC series of pressure sensors.
The country of origin for this sensor is India.
