Hongfa Europe GMBH PCB Power Relay 12V dc Coil 15A Switching Current SPST HF3FA/012-HTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.5mm |
| Length | 19mm |
| Model | HF3FA/012-HTF |
| Width | 15.2mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF3FA |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 15A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 400Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 28V dc |
| Switching AC Voltage | 277V |
| Coil Power | 360mW |
Key Features
- This power relay utilizes silver alloy contacts ensuring reliable conductivity.
- Designed for PCB mounting with a low profile height of 15.5mm.
- Operating temperature range from -40°C to 85°C suitable for diverse environments.
- Offers switching capabilities at 277V AC and 28V DC, up to 2.8kVA power handling.
- Coil resistance measures 400Ω with coil power consumption of 360mW.
- Durability rated up to 10 million operational cycles for industrial reliability.
- Isolation between coil and contact rated at 2.5KV ensuring electrical safety.
- Applicable in automotive engines, household appliances, medical equipment, telecommunications, and industrial machinery.
Product Description
Hongfa Europe GMBH HF3FA/012-HTF PCB Power Relay features a coil voltage of 12V dc and a switching current of 15A in a SPST configuration. Its compact subminiature design allows mounting on printed circuit boards with a low height of 15.5mm and dimensions of 19mm length and 15.2mm width.
The relay contacts utilize a silver alloy material, delivering excellent conductivity and a contact resistance of 100mΩ. It supports switching voltages up to 277V AC and 28V DC and can handle switching power up to 2.8kVA.
Engineered for durability, the relay is rated for up to 10 million operational cycles and provides electrical isolation between coil and contact up to 2.5KV. It operates reliably within a temperature range from -40°C to 85°C and has a coil resistance of 400Ω with consumption of 360mW.
Certified as RoHS compliant, this relay is environmentally friendly and well suited for a variety of industrial and commercial applications including automotive engines, household appliances, industrial machinery, medical devices, and telecommunications equipment.
This power relay utilizes silver alloy contacts ensuring reliable conductivity. Designed for PCB mounting with a low profile height of 15.5mm. Operating temperature range from -40°C to 85°C suitable for diverse environments.
Offers switching capabilities at 277V AC and 28V DC, up to 2.8kVA power handling. Coil resistance measures 400Ω with coil power consumption of 360mW. Durability rated up to 10 million operational cycles for industrial reliability.
Isolation between coil and contact rated at 2.5KV ensuring electrical safety. Applicable in automotive engines, household appliances, medical equipment, telecommunications, and industrial machinery. RoHS compliant product adhering to environmental safety standards.
Explore the Hongfa Europe GMBH range and other Power Relays on EnvMart for industrial and electrical applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switching current of this power relay is 15A.
The coil voltage for the HF3FA/012-HTF is 12V DC.
This model has a height of 15.5mm, a length of 19mm, and a width of 15.2mm.
The maximum operating temperature for this relay is 85°C.
The relay features a Single Pole Single Throw (SPST) contact configuration.
The isolation between the coil and contact is rated at 2.5KV.
The coil resistance of the HF3FA/012-HTF is 400Ω.
The contacts of this relay are made from silver alloy, ensuring reliable conductivity.
This power relay can handle switching power up to 2.8kVA.
The HF3FA/012-HTF is certified as RoHS compliant, adhering to environmental safety standards.
This relay is applicable in automotive engines, household appliances, medical equipment, telecommunications, and industrial machinery.
The durability of the HF3FA/012-HTF is rated for up to 10 million operational cycles.
