Fluke calibration Bench Digital Multimeter True RMS 10 A AC, 10 A DC, 750 V AC Fluke 8808A

Free Delivery in India | Lowest Global Shipping Charges

Fluke calibration Bench Digital Multimeter True RMS 10 A AC, 10 A DC, 750 V AC Fluke 8808A

Name: Fluke calibration Bench Digital Multimeter True RMS 10 A AC, 10 A DC, 750 V AC Fluke 8808A
Brand: Fluke calibration
SKU: 317762
Price: 20.22 USD
Availability: InStock



Category Digital Multimeter Brand Fluke calibration Condition New

Specifications

Country of Origin	China
Display Type	Digital
Brand	Fluke calibration
Height	88mm
Length	297mm
Model	Fluke 8808A
Gross Weight	2.1kg
Width	217mm
Maximum Operating Temperature	50°C
Minimum Operating Temperature	0°C
DC Current Accuracy	0.02% + 0.005
Resistance Measurement Accuracy	0.02% + 0.003
AC Current Accuracy	0.3% + 0.06
Resistance Resolution	1mΩ
AC Current Resolution	100μA
DC Current Resolution	0.001μA dc
Multimeter Type	Bench
Functions Measured	AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance
Maximum Resistance Measurement	0.1GΩ
Maximum AC Current Measurement	10A ac
Maximum DC Voltage Measurement	1kV dc
Maximum DC Current Measurement	10A dc
Maximum AC Voltage Measurement	750V ac
Maximum Frequency	1MHz
Safety Category Level	CAT I, CAT II
Safety Category Voltage	1000V dc
Fluke Multimeter KitBrand	Fluke

Key Features

Provides true RMS AC current and voltage measurements up to 10 A and 750 V respectively.
DC current measurement up to 10 A with 0.02% accuracy plus 0.005 offset.
Measures resistance up to 0.1 GΩ with 1 mΩ resolution for insulation testing.
Supports frequency measurements up to 1 MHz for high-speed signal analysis.
Includes diode test, continuity, AC/DC voltage and current measurement functions.
Operates reliably in ambient temperatures from 0°C to 50°C.
Digital display provides precise readings with resolutions down to 1 μV and 0.001 μA.
Bench model suitable for use in industrial, laboratory, workshop, and calibration applications.

Product Description

Fluke calibration Fluke 8808A Bench Digital Multimeter is a mains-powered bench instrument engineered for precise and reliable electrical measurement in laboratory and workshop environments. It features true RMS capability for accurate AC measurement up to 750 V AC and 10 A current handling in both AC and DC modes.

The instrument boasts outstanding sensitivity with DC voltage resolution of 1 μV and DC current accuracy of 0.02% plus 0.005, enabling fine measurements of low-level signals. Its resistance measurement extends up to 0.1 GΩ with 1 mΩ resolution, making it suitable for insulation and component testing.

Supporting frequency measurements up to 1 MHz, the Fluke 8808A is ideal for high-frequency circuit diagnostics. Its multifunction measurement capabilities include AC/DC voltage and current, resistance, continuity, diode testing, and frequency analysis, covering a wide range of test requirements.

Designed for safety, the multimeter is classified under safety category CAT I and CAT II with a maximum DC voltage rating of 1000 V, ensuring protection during typical laboratory and shop-floor use. Its operating temperature range of 0°C to 50°C allows consistent performance across standard indoor environments.

This bench digital multimeter weighs 2.1 kg and measures 297 mm in length, 217 mm in width, and 88 mm in height, making it a robust and stable instrument for precise measurements. It is manufactured in China and marked as new.

True RMS measurement for accurate AC readings up to 750 V AC. DC current accuracy of 0.02% plus 0.005 for precision tasks. Resistance capability up to 0.1 GΩ with 1 mΩ resolution. Frequency measurement range up to 1 MHz.

Includes diode test and continuity functions. Maximum current handling of 10 A AC and DC. Safety certified CAT I and CAT II at 1000 V DC. Robust bench design for stable measurement performance. Operating ambient temperature range from 0°C to 50°C.

This meter is suitable for use in industrial, laboratory, manufacturing, test and measurement, electrical engineering, and calibration service environments. It supports critical tasks such as power supply output characterization, component level diagnostics, and high-frequency signal analysis.

Explore EnvMart categories for more Digital Multimeters and precision measuring instruments from trusted manufacturers.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The Fluke 8808A can measure AC voltage up to 750 V AC.

The DC current accuracy of this multimeter is 0.02% plus 0.005.

It can measure resistance up to 0.1 GΩ with a resolution of 1 mΩ.

The Fluke 8808A supports frequency measurements up to 1 MHz.

This model measures 297 mm in length, 217 mm in width, and 88 mm in height, weighing 2.1 kg.

It measures AC current, AC voltage, DC current, DC voltage, resistance, continuity, diode test, and frequency.

The operating temperature range is from 0°C to 50°C.

The maximum DC voltage rating is 1000 V DC, classified under safety categories CAT I and CAT II.

The DC voltage resolution is down to 1 μV, allowing for fine measurements of low-level signals.

Yes, it includes a diode test function along with continuity testing.

It features a digital display for precise readings.

This multimeter is suitable for industrial, laboratory, manufacturing, test and measurement, electrical engineering, and calibration service environments.
