Microchip LIN Transceiver 20 kBd, 8-Pin SOIC MCP2021-500E/SN

Free Delivery in India | Lowest Global Shipping Charges

Microchip LIN Transceiver 20 kBd, 8-Pin SOIC MCP2021-500E/SN

Name: Microchip LIN Transceiver 20 kBd, 8-Pin SOIC MCP2021-500E/SN
Brand: Microchip
SKU: 312805
Price: 228.75 INR
Availability: InStock



Category CAN Interface ICs Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	1.25mm
Length	4.9mm
Model	MCP2021-500E/SN
Width	3.9mm
Mount Type	Surface
Series	MCP2021
Maximum Operating Temperature	125°C
Package Type	SOIC
Sub Type	CAN Controller
Minimum Operating Temperature	-40°C
Interface Type	LIN, SAE J2602
Pin Count	8
Maximum Supply Voltage	18V
Minimum Supply Voltage	6V
Supply Current	1mA
Maximum Data Rate	20kBd
Number of Transceivers	1
Extended temperature range	-40 to +125°C
Wide Supply Voltage	6 V to 18 V

Key Features

Supports LIN Bus 1.3, 2.1 and SAE J2602-2 specifications.
Operates with a wide supply voltage range of 6 V to 18 V.
Provides integrated 50mA voltage regulator with 5 V or 3.3 V output.
Features low EMI and 43 V load dump protection.
Extends temperature range from -40 to +125°C for automotive environments.
Includes automatic thermal shutdown and two low-power modes.
Interfaces with EUSART and USART for flexible communication.
Compact 8-pin SOIC surface mount package with dimensions 4.9mm x 3.9mm x 1.25mm.

Product Description

Microchip MCP2021-500E/SN is a LIN Transceiver designed for reliable bi-directional, half-duplex communication at data rates up to 20 kBd. It comes in an 8-pin SOIC surface mount package measuring 4.9 mm in length, 3.9 mm in width, and 1.25 mm in height. This device interfaces between microcontrollers and Local Interconnect Networks (LIN), compliant with LIN 1.3, 2.1 and the SAE J2602-2 specification standards.

The MCP2021 integrates a 50mA voltage regulator providing either 5 V or 3.3 V output depending on the model variant, thus simplifying power management. It supports a broad supply voltage range from 6 V up to 18 V, enabling operation in diverse automotive and industrial environments.

Key features include low electromagnetic interference (EMI), protection against 43 V transient load dump events, and an extended operating temperature range from -40°C to +125°C ensuring robustness in harsh conditions. Thermal management is enhanced through automatic thermal shutdown and dual low-power modes, optimizing energy use and safety.

The IC is compatible with common microcontroller communication protocols via an EUSART and USART interface, guaranteeing flexible integration for varied applications.

This LIN transceiver is ideal for automotive electronics, industrial control systems, laboratory communication networks, and other embedded system connectivity solutions requiring a rugged and compliant CAN bus transceiver IC.

Supports LIN Bus 1.3, 2.1, and SAE J2602 standards. Wide supply voltage from 6 V to 18 V accommodates multiple system architectures. On-chip 50mA voltage regulator simplifies design requirements. Robust protection features including low EMI and 43 V load dump tolerance.

Extended temperature range supports automotive and industrial use. Compact SOIC 8-pin package suitable for surface mounting. Low current consumption improves efficiency. Interfaces easily with standard microcontroller serial ports.

Explore EnvMart's extensive catalog of semiconductor components and CAN Interface ICs for reliable and compliant communication solutions across industries.
