Schneider Electric Miniature Circuit Breaker 3-Pole 16A Type C 400V AC 4500A Breaking Capacity A9PA2316
Specifications
| Country of Origin | Hungary |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 85mm |
| Model | A9PA2316 |
| Depth | 74mm |
| Width | 54mm |
| Mount Type | DIN Rail |
| Current Rating | 16A |
| Series | Acti9 iDT40 |
| Terminal type | Screwless Terminal |
| Breaking Capacity | 4500A |
| Number of Poles | 3 |
| Standards/Approvals | EN/IEC 60898-1 EN/IEC 60947-2 |
| Rated AC Voltage | 400V |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Features a 3-pole configuration for multi-phase circuit protection.
- Rated for 16 amperes current, suitable for moderate electrical loads.
- Type C tripping characteristics ensure appropriate response to overloads.
- Operates reliably at a rated AC voltage of 400V.
- Provides a breaking capacity of 4500 amperes for short circuit conditions.
- Mounts easily on DIN rails for secure installation.
- Incorporates screwless terminal connections for quicker wiring.
- Reset actuator features a toggle switch for manual control.
Product Description
Schneider Electric A9PA2316 Miniature Circuit Breaker is a 3-pole device rated at 16A with Type C tripping characteristics, designed for industrial and commercial electrical distribution systems. It operates at 400 volts AC and can safely interrupt fault currents up to 4500 amperes. The breaker uses thermal magnetic technology for tripping, providing reliable protection against overloads and short circuits.
This device is part of the Acti9 iDT40 series, featuring a screwless terminal design that simplifies installation and maintenance. Its compact size, with dimensions of 85mm height, 54mm width, and 74mm depth, makes it suitable for DIN rail mounting in standard electrical panels.
The toggle switch actuator allows for straightforward manual reset, enhancing usability in both new installations and maintenance scenarios. Designed to meet EN/IEC 60898-1 and EN/IEC 60947-2 standards, this miniature circuit breaker is engineered for safety and compliance in accordance with international electrical regulation standards.
The circuit breaker has an IP20 and IP40 degree of protection and supports pollution degree 3 environments, making it versatile for various industrial and commercial applications. 3-pole configuration for multi-phase protection.
Rated current 16 amperes suitable for moderate load circuits. Type C trip curve for protection against short-circuits with moderate inrush current tolerance. Breaking capacity of 4500 amperes for fault interruption. Mounts on DIN rail for modular panel assembly.
Screwless terminals enhance installation speed and reliability. Compact dimensions facilitate use in space-limited enclosures. Toggle switch for manual breaker reset. Conforms to EN/IEC 60898-1 and EN/IEC 60947-2 electrical standards.
This Miniature Circuit Breaker is ideal for use in industrial, commercial, and residential electrical distribution boards, supporting electrical safety and system integrity. Schneider Electric’s Acti9 iDT40 series ensures quality and dependable protection, suitable for a wide range of electrical applications including lighting, control panels, and machinery protection.
Explore more products from Schneider Electric and other electrical distribution components on EnvMart to find compatible solutions for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this miniature circuit breaker is 4500 amperes, allowing it to safely interrupt fault currents during short circuit conditions.
This model is rated for a current of 16 amperes, making it suitable for moderate electrical loads.
The dimensions of this circuit breaker are 85mm in height, 54mm in width, and 74mm in depth.
It mounts on DIN rails, which facilitates secure installation in standard electrical panels.
It features Type C tripping characteristics, which provide appropriate response to overloads and short circuits with moderate inrush current tolerance.
The rated AC voltage for this model is 400 volts, suitable for various industrial and commercial applications.
It complies with EN/IEC 60898-1 and EN/IEC 60947-2 standards, ensuring safety and compliance with international electrical regulations.
The reset actuator features a toggle switch for manual control, enhancing usability during maintenance and operation.
It incorporates screwless terminals, which simplify installation and improve wiring speed and reliability.
This model supports pollution degree 3 environments, making it versatile for various applications.
This circuit breaker is part of the Acti9 iDT40 series, which is designed for industrial and commercial electrical distribution systems.
The country of origin for this miniature circuit breaker is Hungary.
