Schneider Electric Miniature Circuit Breaker 3-Pole, 32A, Type C, 400V AC, 6000A Breaking Capacity A9PA4332
Specifications
| Country of Origin | Hungary |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 85mm |
| Model | A9PA4332 |
| Depth | 74mm |
| IP Rating | IP20 |
| Width | 54mm |
| Mount Type | DIN Rail |
| Current Rating | 32A |
| Series | Acti9 iDT40N XA |
| Breaking Capacity | 6000A |
| Number of Poles | 3 |
| Standards/Approvals | EN/IEC 60947-2, EN/IEC 60898-1 |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Three-pole configuration for multi-phase circuit protection.
- Type C tripping characteristics suitable for general applications.
- Toggles control with clear ON/OFF and trip indication.
- Compliance with IEC/EN standards 60947-2 and 60898-1 ensures quality and safety.
- Compact design with dimensions 54mm width, 74mm depth, and 85mm height.
- Mounts easily on DIN rail with clip-on mounting mode.
- Thermal magnetic trip unit technology delivers excellent overload and short circuit protection.
- Rated for ambient operation from -25°C to 70°C with 95% relative humidity tolerance.
Product Description
Schneider Electric A9PA4332 Miniature Circuit Breaker is a high-performance 3-pole device with a current rating of 32A and type C tripping characteristic. Operating at a rated voltage of 400V AC with a breaking capacity of 6000A, it provides excellent protection for electrical circuits against short circuit and overload faults.
Featuring a thermal magnetic tripping mechanism, the breaker combines fast response to short circuits with reliable protection against overloads, ensuring safety and reliability in various industrial and commercial applications. It is designed with a toggle switch actuator to easily control ON/OFF states and displays a trip indicator for quick fault identification.
This circuit breaker complies with international standards EN/IEC 60947-2 and EN/IEC 60898-1, guaranteeing quality and compatibility with modular electrical systems. The device is rated IP20, protecting against solid object ingress while suitable for indoor electrical panel environments. Its compact dimensions (54mm width, 74mm depth, 85mm height) allow space-saving installations on DIN rails with clip-on mounting.
Operational conditions for the A9PA4332 include an ambient temperature range from -25°C to 70°C and tolerance to up to 95% relative humidity, making it robust in varied environments. The breaker is padlockable for added safety during maintenance or shutdowns, enhancing the protection of operators and equipment. With an impulse withstand voltage of 4 kV, it resists damaging transient voltages effectively.
This miniature circuit breaker is ideal for electrical distribution boards in industrial, commercial, and residential installations requiring reliable and certified circuit protection. It is part of Schneider Electric's Acti9 range, known for premium quality and performance.
Three-pole configuration for multi-phase circuit protection. Type C tripping characteristics suitable for general applications. Toggles control with clear ON/OFF and trip indication. Compliance with IEC/EN standards 60947-2 and 60898-1 ensures quality and safety.
Compact design with dimensions 54mm width, 74mm depth, and 85mm height. Mounts easily on DIN rail with clip-on mounting mode. Thermal magnetic trip unit technology delivers excellent overload and short circuit protection.
Rated for ambient operation from -25°C to 70°C with 95% relative humidity tolerance. Padlockable switch provides enhanced safety during maintenance. Impulse withstand voltage of 4 kV supports durability under transient conditions.
Explore more electrical protection equipment from Schneider Electric in the Miniature Circuit Breaker category at EnvMart for your industrial and electrical automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this miniature circuit breaker is 32A.
This model has a breaking capacity of 6000A.
The dimensions of this circuit breaker are 54mm in width, 74mm in depth, and 85mm in height.
It utilizes a thermal magnetic tripping mechanism for overload and short circuit protection.
The rated AC voltage for this circuit breaker is 400V AC.
It mounts easily on DIN rails using a clip-on mounting mode.
The tripping characteristics are Type C, suitable for general applications.
The IP rating of this model is IP20, which protects against solid object ingress.
It operates within an ambient temperature range of -25°C to 70°C.
It complies with EN/IEC 60947-2 and EN/IEC 60898-1 standards.
Yes, it features a padlockable switch for enhanced safety during maintenance.
This circuit breaker belongs to the Acti9 series.
