Relpol PCB Power Relay 12V DC Coil 5A Switching Current SPDT RM40-2011-85-1012
Specifications
| Country of Origin | Poland |
|---|---|
| Brand | Relpol |
| Height | 10.5mm |
| Length | 20mm |
| Model | RM40-2011-85-1012 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | RM40 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 5A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS, VDE |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 48V dc |
| Switching AC Voltage | 380V ac |
| Coil Power | 200mW |
Key Features
- The relay features a compact RM40 series design suitable for electronic and automotive applications.
- Coil voltage rating of 12V DC ensures reliable operation in DC circuits.
- Contact configuration is SPDT for versatile switching needs.
- Supports switching currents up to 5A and voltages up to 48V DC and 380V AC.
- Constructed with a silver alloy contact material for excellent conductivity and durability.
- Coil resistance is rated at 720 ohms, consuming 200mW power.
- Compact dimensions of 20mm length, 10mm width, and 10.5mm height enable easy PCB integration.
- Operating temperature range of -40°C to 85°C permits use in diverse environments.
Product Description
Relpol RM40-2011-85-1012 PCB Power Relay is a high-quality SPDT relay designed for general purpose applications such as automotive, machine control, and electronic equipment requiring PCB mounting. Featuring a 12V DC coil voltage, this relay supports a switching current of 5A, making it suitable for medium-load electrical switching tasks.
The RM40 series relay is compact with dimensions of 20mm length, 10mm width, and 10.5mm height, facilitating easy integration on printed circuit boards. It employs silver alloy contact material, providing excellent electrical conductivity and long-lasting performance. The relay coil resistance of 720Ω and coil power of 200mW ensures efficient energy consumption during operation.
It is rated for switching voltages up to 48V DC and 380V AC, with a switching power of 250 VA, enabling broad versatility in both AC and DC applications. The device operates reliably in harsh conditions with a temperature range from -40°C to 85°C and possesses high resistance to shock and vibration, making it ideal for industrial and automotive environments.
Relpol RM40 series relays comply with international safety standards including RoHS and VDE, guaranteeing environmentally safe materials and quality assurance. The relay terminals are designed as PCB pins for secure mounting and easy soldering.
The relay offers a compact solution for power switching tasks on PCBs. Reliable SPDT contact configuration for flexible switching applications. Durable silver alloy contacts for long service life. Wide operating temperature range supports industrial use.
Energy-efficient coil with 12V DC voltage and 720Ω resistance. High voltage and current handling capacity ensure versatile application. Compliant with RoHS and VDE standards for safety and quality. Suitable for automotive, manufacturing, HVAC, and electronic equipment.
This Relpol Power Relay is an essential component for electronic engineers and system integrators aiming for reliable and compact switching solutions. Explore more components and accessories in the Electronics & Electricals category at EnvMart for professional industrial and commercial deployment.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a coil voltage rating of 12V DC, ensuring reliable operation in DC circuits.
It supports a maximum switching current of 5A, making it suitable for medium-load electrical switching tasks.
This relay has compact dimensions of 20mm in length, 10mm in width, and 10.5mm in height, facilitating easy integration on printed circuit boards.
The relay features a Single Pole Double Throw (SPDT) contact configuration, allowing for versatile switching needs.
The maximum operating temperature is 85°C, allowing it to function in diverse environments.
It is constructed with silver alloy contact material, which provides excellent conductivity and durability.
The coil resistance is rated at 720 ohms, consuming 200mW of power during operation.
This relay can switch voltages up to 48V DC and 380V AC, providing versatility in both AC and DC applications.
The relay is designed for PCB mounting with terminals that are PCB pins for secure mounting and easy soldering.
It complies with RoHS and VDE standards, ensuring environmentally safe materials and quality assurance.
The minimum operating temperature is -40°C, enabling reliable performance in harsh conditions.
This model is suitable for general purpose applications such as automotive, machine control, and electronic equipment requiring PCB mounting.
