Siemens Inverter Drive SINAMICS G115D Series Panel Mount, 750 W, 3 Phase, 480V, 2.6 A 6SL3520-3XH20-7AA0

Free Delivery in India | Lowest Global Shipping Charges

Siemens Inverter Drive SINAMICS G115D Series Panel Mount, 750 W, 3 Phase, 480V, 2.6 A 6SL3520-3XH20-7AA0

Name: Siemens Inverter Drive SINAMICS G115D Series Panel Mount, 750 W, 3 Phase, 480V, 2.6 A 6SL3520-3XH20-7AA0
Brand: Siemens
SKU: 298463
Price: 2343.21 USD
Availability: InStock



Category Inverter Drive Brand Siemens Condition New

Specifications

Country of Origin	United Kingdom
Brand	Siemens
Model	6SL3520-3XH20-7AA0
IP Rating	IP65, IP66
Mount Type	Panel
Series	SINAMICS G115D
Overall Width	380mm
Power Rating	750W
Maximum Operating Temperature	55°C
Output Frequency	550Hz
Minimum Operating Temperature	-30°C
Number of Phases	3
Maximum Output Current	2.6A
Standards/Approvals	CE, C-Tick (RCM), EAC, KCC, REACH, SEMI F47
Maximum Supply Voltage	480V
Overall Depth	129mm
Minimum Supply Voltage	380V
Better World Claim	Saves Energy

Key Features

Robust panel mount inverter drive suitable for industrial automation.
Supports output frequency up to 550 Hz for precise motor control.
IP65 and IP66 rated for protection against dust and water ingress.
Operates reliably from -30°C to 55°C ambient temperature.
Offers integrated safety with STO function and fail safe digital input.
Compatible with SIMOGEAR geared motors of efficiency classes IE3 and IE4.
Compact dimensions with 380 mm width and 129 mm depth.
Certified with CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47 standards.

Product Description

Siemens 6SL3520-3XH20-7AA0 is a high-performance inverter drive from the SINAMICS G115D series, delivering 750 W power and designed for use in industrial automation, manufacturing, and conveyor systems. This panel-mounted three-phase drive supports supply voltages from 380 V to 480 V and provides a maximum output current of 2.6 A, enabling precise speed control and energy-efficient operation.

Built to withstand demanding industrial environments, the unit features IP65 and IP66 ingress protection and operates reliably in temperatures ranging from -30°C to 55°C. Its compact form factor with 380 mm width and 129 mm depth simplifies integration into machine assemblies and control cabinets.

The drive includes integrated safety functions such as Safe Torque Off (STO) and a fail-safe digital input, facilitating compliance with modern safety standards. It supports SIMOGEAR asynchronous and synchronous reluctance motors with high efficiency ratings of IE3 and IE4, making it suitable for applications requiring energy savings.

This SINAMICS G115D drive excels in horizontal conveyor system applications, offering capabilities from simple speed control to sophisticated encoderless vector control. Its modular design eliminates the need for separate control cabinets, reducing space and cooling requirements, while enabling quick and easy installation, cabling, and commissioning.

Robust panel mount inverter drive suitable for industrial automation. Supports output frequency up to 550 Hz for precise motor control. IP65 and IP66 rated for protection against dust and water ingress. Operates reliably from -30°C to 55°C ambient temperature.

Offers integrated safety with STO function and fail safe digital input. Compatible with SIMOGEAR geared motors of efficiency classes IE3 and IE4. Compact dimensions with 380 mm width and 129 mm depth. Certified with CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47 standards.

Designed for horizontal conveyor applications requiring encoderless vector control.

This inverter drive is an ideal solution for industries requiring robust, energy-saving, and compact frequency converters, suitable for construction, manufacturing, material handling, HVAC, and water treatment applications.
