Microchip 12 bit AVR ATTINY Microcontroller 20 MHz 8kB FLASH 14-Pin SOIC ATTINY824-SSU

Microchip ATTINY824-SSU 12 bit AVR Microcontroller is a compact and energy-efficient embedded controller operating at up to 20 MHz in a 14-Pin SOIC package. It integrates 8 KB of FLASH program memory, 1 KB SRAM, and 128 bytes EEPROM memory, enabling sufficient space for code and data storage in embedded applications.

Equipped with an AVR CPU core featuring a hardware multiplier, it supports high performance computation while maintaining low power operation, suitable for battery-powered or industrial devices. The device includes 12 programmable I/O pins, 9 channels of 12-bit ADC with programmable gain amplifier for precise analog signal acquisition, and an analog comparator with an internal DAC reference for signal conditioning.

Communication interfaces include dual USARTs, SPI, and I2C, making it highly flexible for various data exchange protocols in complex embedded systems. The microcontroller operates over an extended voltage range from 1.8 V to 5.5 V, supporting low voltage applications without sacrificing performance.

Additional features such as 3 timers and advanced Core Independent Peripherals including a 6-channel Event System and Configurable Custom Logic enhance its capability in real-time control and signal processing tasks. This makes it ideal for applications in industrial automation, consumer electronics, medical devices, and automotive controls where reliable and efficient microcontrollers are critical.

The SOIC surface mount package ensures ease of assembly and integration on compact PCBs, suitable for mass production.

Overall, the ATTINY824-SSU is a versatile microcontroller that balances performance, features, and size for embedded system designers requiring 12-bit ADC accuracy and flexible communication options.

Operates with a maximum clock frequency of 20 MHz. Incorporates 8kB of FLASH program memory and 1 KB SRAM. Contains 12 programmable I/O pins suitable for embedded applications. Offers 9x12 bit ADC channels with programmable gain amplifier for accurate analog measurements.

Includes an analog comparator with internal DAC reference to support signal processing tasks. Features 3 timers and 2 USART serial communication interfaces along with SPI and I2C buses. Operates over a voltage range from 1.8V to 5.5V, suitable for low power designs.

Designed with AVR CPU having a hardware multiplier and advanced Core Independent Peripherals. Suitable for industrial, automotive, consumer electronics, and embedded systems. Package type is SOIC with surface mount for compact PCB assembly.
