Hager xPole PXL 2-Pole Miniature Circuit Breaker 6A Current Rating Type C 400V AC 48V DC 10kA Breaking 236278 PXL-C6/2
Specifications
| Country of Origin | Austria |
|---|---|
| Range | xPole |
| Brand | Hager |
| Height | 35mm |
| Model | 236278 PXL-C6/2 |
| Depth | 60mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 6A |
| Series | PXL |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Standards/Approvals | EN 60898, IEC |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| Hager Invicta NCN MCB2P, 6A Curve C, 230 → 400V AC, 10 kA Breaking CapacityBrand | Hager |
Key Features
- Designed for mounting on standard DIN rails for easy installation.
- Offers a breaking capacity of 10kA to safely interrupt fault currents.
- Features a toggle switch for manual reset and status indication.
- Includes touch-proof IP20 rating ensuring operator safety from electric shocks.
- Complies with IEC and EN 60898 standards for circuit protection.
- Equipped with double terminals enabling connection of two separate circuits.
- Compact dimensions (80mm width, 35mm height, 60mm depth) optimize panel space.
- Tripping mechanism operates electromagnetically with instantaneous response.
Product Description
Eaton 236278 PXL-C6/2 is a 2-pole miniature circuit breaker from the xPole PXL series designed for industrial and commercial electrical protection. It provides a current rating of 6 amps with Type C tripping sensitivity, suitable for protecting circuits with moderate inrush current such as lighting and motor circuits.
The breaker supports rated voltages of 400V AC and 48V DC, making it versatile for AC and DC supply use cases. Its 10kA breaking capacity ensures reliable clearing of short-circuit faults to protect equipment and personnel.
The device mounts easily on DIN rails and features an IP20 touch-proof rating to prevent accidental contact with live parts, enhancing operator safety during installation and maintenance.
This miniature circuit breaker is equipped with a toggle switch actuator for clear on/off position indication and quick manual reset. The electromagnetic tripping mechanism acts instantaneously to minimize fault duration.
Supplied from Austria and compliant with IEC and EN 60898 standards, this Eaton circuit breaker is suitable for use in industrial automation systems, electrical distribution panels, and commercial installations requiring reliable branch circuit protection.
Mounts on standard top-hat rail (IEC/EN 60715) with quick-fit locking positions. Includes bus bar compatibility and double terminal lift/jaw connections for secure wiring. Finger-proof design prevents electrical shock risk during operation.
Two-pole design enables independent control and protection of separate circuits. Ideal for use in manufacturing plants, building electrical systems, HVAC controls, and water treatment facilities. This PXL series xPole breaker balances high selectivity with low passband energy, making it effective as a pre-fuse and overload protection device.
EnvMart offers this Eaton 236278 PXL-C6/2 Miniature Circuit Breaker as a dependable component for electrical engineers and technicians seeking high quality circuit protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 6 amps.
It offers a breaking capacity of 10kA, ensuring reliable interruption of fault currents.
The breaker supports rated voltages of 400V AC and 48V DC, making it versatile for various applications.
It features an electromagnetic tripping mechanism that operates instantaneously to minimize fault duration.
It is designed for mounting on standard DIN rails, facilitating easy installation.
The dimensions are 80mm in width, 35mm in height, and 60mm in depth.
It has an IP20 rating, providing touch-proof protection against accidental contact with live parts.
It complies with IEC and EN 60898 standards for circuit protection.
It includes a toggle switch actuator for manual reset and status indication.
This model is suitable for use in industrial automation systems, electrical distribution panels, and commercial installations.
This circuit breaker has a 2-pole design, allowing for independent control and protection of separate circuits.
It features Type C tripping characteristics, suitable for circuits with moderate inrush currents.
