Siemens SINAMICS G115D Converter AC Input 380V-480V, Max Output Current 8.2A 6SL3520-2XC01-5AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Height | 156mm |
| Length | 129mm |
| Model | 6SL3520-2XC01-5AF0 |
| Width | 380mm |
| Mount Type | Wall |
| Series | SINAMICS G115D |
| Input Type | AC |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | 30°C |
| Standards/Approvals | UL, RoHS, REACH, SEMI F47, Low-Voltage Directive 2014/35/EC, KCC, EMC Directive 2014/30/EC, EAC, cUL, C-Tick (RCM), CE |
| Maximum Supply Voltage | 480V |
| Minimum Supply Voltage | 380V |
| Maximum High Level Output Current | 8.2A |
| Maximum Low Level Output Current | 4.1A |
Key Features
- Supports SIMOGEAR 2KJ8 geared motors and three-phase asynchronous motors with efficiency class IE3.
- Designed for horizontal conveyor systems with sophisticated encoderless vector control.
- Integrated safety features including STO function with fail safe digital input F-DI and PROFIsafe.
- Wall mount type for easy installation directly on machines, reducing space and cooling requirements.
- Robust and modular design facilitating quick cabling and commissioning processes.
- Operates in ambient temperatures from 30°C up to 55°C for reliable performance.
- Complies with multiple standards such as UL, RoHS, REACH, Low-Voltage Directive, EMC Directive, and CE marking.
- Compact dimensions of 129mm length, 156mm height, and 380mm width.
Product Description
Siemens 6SL3520-2XC01-5AF0 is a high-quality converter from the SINAMICS G115D series designed for demanding industrial environments. It accepts an AC input voltage ranging from 380V to 480V and provides maximum high level output current of 8.2A, suitable for precise motor control in automation systems.
This converter supports SIMOGEAR 2KJ8 geared motors as well as three-phase asynchronous motors with efficiency class IE3 or high efficiency synchronous reluctance motors with efficiency class IE4. It is tailored for horizontal conveyor systems, enabling applications from simple speed adjustments to sophisticated encoderless vector control performance.
The product features integrated safety with STO function enhanced by fail safe digital input F-DI and PROFIsafe capabilities, ensuring compliance with modern safety requirements in manufacturing setups.
Its modular and user-friendly design allows installation on the machine itself without requiring a control cabinet. This feature reduces space usage and lowers cooling demands, making it a versatile and cost-effective solution. The wall mount type facilitates quick and easy installation, cabling, and commissioning.
Operating reliably within a temperature range of 30°C to 55°C, the converter’s robust construction meets international standards and approvals including UL, RoHS, REACH, SEMI F47, Low-Voltage Directive 2014/35/EC, KCC, EMC Directive 2014/30/EC, EAC, cUL, C-Tick (RCM), and CE marking.
With physical dimensions measuring 129mm in length, 156mm in height, and 380mm in width, this converter is compact yet powerful, suitable for industrial automation, manufacturing, and material handling applications.
Supports SIMOGEAR geared motors and high efficiency asynchronous motors. Integrated safety features including STO function and PROFIsafe compatibility. Wall-mount design enables direct machine installation saving space and cooling.
Comprehensive approvals and standards compliance ensure reliable industrial use. Designed for horizontal conveyor system applications and industrial automation. Explore EnvMart’s extensive range of Siemens Converters and industrial automation products to enhance your manufacturing and automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The converter accepts an AC input voltage ranging from 380V to 480V.
It provides a maximum high level output current of 8.2A.
The dimensions are 129mm in length, 156mm in height, and 380mm in width.
It supports SIMOGEAR 2KJ8 geared motors and three-phase asynchronous motors with efficiency class IE3.
It includes an STO function with a fail-safe digital input F-DI and PROFIsafe capabilities for enhanced safety.
The operating temperature range is from 30°C to 55°C.
It features a wall mount type design, allowing for easy installation directly on machines.
It complies with multiple standards including UL, RoHS, REACH, and CE marking, among others.
This model belongs to the SINAMICS G115D series.
The minimum operating temperature is 30°C.
The maximum low level output current is 4.1A.
It is designed for horizontal conveyor systems and industrial automation applications.
