Texas Instruments Buck Converter Through Hole, 15V Output Voltage, 6 A Output Current, 90W Power, DIP Package PTN78020WAH

Texas Instruments PTN78020WAH Buck Converter belongs to the SIMPLE SWITCHER® family of non-isolated step-down switching voltage regulator modules designed for highly efficient DC-DC conversion. This through-hole DIP package module delivers a stable 15V output voltage at 6A current with 90W of power, suitable for low-power applications requiring reliable voltage regulation.

The converter integrates a shielded inductor along with precision enable, soft-start, and tracking functionalities which enable exceptional thermal performance and EMI protection. It supports a wide input voltage range from 15V minimum to 36V maximum, making it adaptable to various power source conditions.

Operating reliably in temperatures ranging from -40°C to 85°C, this module is ideal for industrial, manufacturing, electrical, and embedded system applications that demand high performance and durability. It features ±10% line and load regulation tolerances and maintains ripple and noise below 1%, ensuring power stability for sensitive electronic circuits.

With compact dimensions (37.97mm length, 22.1mm width, 0.4mm depth) and a light gross weight of 7.3g, the PTN78020WAH module facilitates efficient PCB layout designs without sacrificing performance. It complies with RoHS and passes the EN55022 (CISPR22) Class B radiated and conducted EMI standards, supporting environmentally conscious and low-interference system designs.

Applications for this buck converter include power supplies for communication devices, industrial control systems, computing equipment, and other electronics where compact, reliable DC voltage conversion is essential. The high MTBF rating of 5,600,000 hours underscores its suitability for long-term industrial use.

High efficiency of 96% for reduced energy loss and heat generation. 7-pin DIP package enabling easy through-hole mounting on PCBs. Wide operational temperature range from -40°C to 85°C. Non-isolated step-down design suitable for compact power solutions.

Integrated shielded inductor and advanced features improve EMI and thermal handling. Compliance with RoHS and EN55022 Class B EMI standards. Stable output with ±10% load and line regulation. Supports input voltages from 15V to 36V for flexibility.

Compact size with precision engineering ideal for industrial applications. Long MTBF of 5.6 million hours ensures reliability. Explore a wide range of high-quality DC-DC Converters and power management solutions at EnvMart for your electronics and industrial automation needs.
