IXYS High Voltage Diode 2200 V 310 A 3-Pin Panel Mount Y1-CU MDD312-22N1

The IXYS MDD312-22N1 is a high voltage diode module designed primarily for industrial and heavy-duty electronic applications requiring robust rectification and high current capacity.

Featuring a panel mount design with a Y1-CU package type, this diode module supports a maximum continuous forward current of 310 A and a peak reverse repetitive voltage of 2200 V, making it ideal for power conversion and control circuits.

Its 3-pin configuration in series ensures efficient performance and heat dissipation, supported by a maximum operating temperature of 150°C and a wide operating temperature range down to -40°C.

The diode offers a maximum forward voltage of 1.32 V, minimizing energy loss during conduction, and it can handle peak non-repetitive forward surge currents up to 11.9 kA, ensuring reliability under transient conditions.

The compact dimensions of 115 mm length, 50 mm width, and 49 mm height enable integration into various industrial panels and electronic assemblies.

This IXYS diode module is well-suited for applications in power supplies, motor drives, industrial automation, and other sectors requiring high voltage and current management with durable, panel-mount components.

This diode features a panel mount type with Y1-CU package for enhanced durability. It supports a maximum continuous forward current of 310 amperes, suitable for heavy-duty applications. The device has a peak reverse repetitive voltage of 2200 volts, ensuring reliable high-voltage operation.

Designed with 3 pins and a Diode configuration in series for efficient rectification. Capable of withstanding peak non-repetitive forward surge current up to 11.9 kiloamperes. Operates reliably within a temperature range from -40°C to 150°C for industrial environments.

The maximum forward voltage is rated at 1.32 volts to optimize power efficiency. The physical dimensions measure 115 mm in length, 50 mm in width, and 49 mm in height, making it suitable for various panel sizes. Explore our Electronics & Electricals category for more semiconductor solutions and high voltage rectifier components at EnvMart.
