Microchip 10 bit Digital to Analogue Converter DAC, SPI Interface, 8-Pin SOIC MCP4911-E/SN
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 10 bit |
| Brand | Microchip |
| Height | 1.7mm |
| Length | 4.9mm |
| Model | MCP4911-E/SN |
| Width | 6mm |
| Mount Type | Surface |
| Settling Time | 4.5μs |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Interface Type | SPI |
| Architecture | Resistor String |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
Key Features
- The architecture employs a resistor string design for accurate output.
- Resolution is 10 bit, supporting single channel output.
- Surface mount type with an 8-pin SOIC package ensures compact integration.
- Operates over a voltage range of 2.7V to 5.5V for versatile applications.
- Operating temperature range from -40°C to 125°C suits industrial environments.
- Fast settling time of 4.5 microseconds for rapid data conversion.
- Uses SPI interface for reliable digital communication.
- Compact dimensions allow efficient PCB design.
Product Description
Microchip MCP4911-E/SN is a high-performance 10 bit Digital to Analogue Converter (DAC) featuring a resistor string architecture and SPI interface communication. Packaged in an 8-pin SOIC surface mount, this DAC offers precision analogue voltage output with a resolution of 10 bits. It is designed to operate efficiently within a supply voltage range of 2.7V to 5.5V, making it adaptable for various electronic and industrial applications.
The device supports a single output channel, ensuring focused and accurate control of analogue signals. It operates reliably across a wide temperature range from -40°C to 125°C, enabling use in harsh industrial environments. The fast settling time of 4.5 microseconds enables quick data processing suitable for dynamic control systems.
With compact dimensions of 4.9mm length, 6mm width, and 1.7mm height, the MCP4911-E/SN is ideal for space-constrained circuit boards. Its SPI interface facilitates easy integration with microcontrollers and embedded systems for digital control of analogue signals.
This DAC outputs a smooth analogue voltage signal, suitable for industrial automation, signal generation, and instrumentation tasks. The component does not carry specific standards or automotive certifications, indicating general industrial use case suitability.
Applications include digital control systems, measurement instruments, data acquisition, and embedded electronics requiring precise digital-to-analogue conversion. The surface mount package ensures compatibility with automated assembly and production efficiency.
The architecture employs a resistor string design for accurate output. Resolution is 10 bit, supporting single channel output. Surface mount type with an 8-pin SOIC package ensures compact integration. Operates over a voltage range of 2.7V to 5.5V for versatile applications.
Operating temperature range from -40°C to 125°C suits industrial environments. Fast settling time of 4.5 microseconds for rapid data conversion. Uses SPI interface for reliable digital communication. Compact dimensions allow efficient PCB design.
Suitable for industrial and embedded system applications requiring high precision. Explore more semiconductor solutions and Digital to Analogue Converters at EnvMart for reliable industrial and electronics applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP4911-E/SN DAC has a resolution of 10 bits, allowing for precise analogue voltage output.
It operates over a supply voltage range of 2.7V to 5.5V, making it suitable for various applications.
The device can operate in temperatures ranging from -40°C to 125°C, which is suitable for industrial environments.
It has a fast settling time of 4.5 microseconds, enabling rapid data conversion.
The MCP4911-E/SN uses an SPI interface for reliable digital communication with microcontrollers and embedded systems.
It is packaged in an 8-pin SOIC surface mount configuration, allowing for compact integration on circuit boards.
The MCP4911-E/SN provides an analogue voltage output, suitable for various applications requiring precise signal control.
It employs a resistor string architecture for accurate output performance.
The dimensions are 4.9mm in length, 6mm in width, and 1.7mm in height, making it compact for PCB design.
It is suitable for applications such as digital control systems, measurement instruments, and data acquisition tasks.
The MCP4911-E/SN does not carry specific standards or automotive certifications, indicating general industrial use suitability.
This model supports a single output channel, ensuring focused and accurate control of analogue signals.
