Nexperia 30 V 500 mA Schottky Barrier Diode 3-Pin SOT-23 Package PMEG3005CT,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 30 V 500 mA Schottky Barrier Diode 3-Pin SOT-23 Package PMEG3005CT,215

Name: Nexperia 30 V 500 mA Schottky Barrier Diode 3-Pin SOT-23 Package PMEG3005CT,215
Brand: Nexperia
SKU: 292416
Price: 0.15 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	PMEG3005CT,215
Width	1.4mm
Mount Type	Surface
Series	PMEG3005CT
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	500mA
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Common Cathode
Rectifier Type	Schottky
Peak Reverse Current Ir	150μA
Peak Non-Repetitive Forward Surge Current Ifsm	10A
Maximum Forward Voltage Vf	430mV
Peak Reverse Recovery Time trr	17ns
onsemi 30 V 200 mA Diode Schottky 3-Pin SOT-23 SBAT54CLT1GBrand	onsemi

Key Features

Features a 30 V peak reverse voltage rating suitable for various electronic applications.
Capable of 500 mA maximum continuous forward current for moderate load conditions.
Equipped with common cathode diode configuration in a 3-pin SOT-23 package.
Provides fast switching with peak reverse recovery time of 17 ns to reduce switching losses.
Operates reliably within a temperature range from -55°C to 150°C for robust performance.
Low forward voltage of 430 mV optimizes efficiency in power management.
Complies with automotive standard AEC-Q101 ensuring quality for automotive applications.
Includes low peak reverse current of 150 µA minimizing leakage in standby modes.

Product Description

Nexperia PMEG3005CT,215 is a high-efficiency Schottky barrier diode with a maximum continuous forward current of 500 mA and a peak reverse voltage of 30 V. Its low profile 3-pin SOT-23 surface mount package suits compact electronic circuits where power efficiency and fast switching are critical.

This diode features a common cathode configuration and achieves a low forward voltage drop of 430 mV, reducing power dissipation in switch mode power supplies and other power management devices. Its fast reverse recovery time of 17 ns enables efficient switching performance, minimizing energy losses in high frequency applications.

Operating within a wide temperature range of -55°C to 150°C and conforming to the automotive AEC-Q101 standard, this diode is well suited for automotive, industrial, and commercial electronics requiring reliable and robust semiconductor components.

The compact package size (3 mm length, 1.4 mm width, 1.1 mm height) allows easy integration on dense printed circuit boards. With a low peak reverse current of 150 µA, it provides minimal leakage current, improving standby efficiency in electronic systems.

Manufactured in China, this component meets modern electronic industry demands for quality, durability, and efficiency. Typical applications include power rectification, voltage clamping, and DC-DC converters in industrial, automotive, and consumer electronics.

30 V peak reverse voltage suitable for discrete semiconductor applications. 500 mA forward current supports moderate power loads. Low forward voltage drop reduces conduction losses. 17 ns reverse recovery time enhances switching efficiency.

Wide operating temperature -55°C to 150°C for harsh environments. Automotive grade compliance (AEC-Q101) ensures reliability. Compact 3-pin SOT-23 surface mount package for dense PCB design.

This Nexperia diode is available through EnvMart for industrial and commercial electronics manufacturing needs. Explore more semiconductor and Schottky diode solutions on EnvMart to source reliable components optimized for your application.
