Vishay 6.8 V 500 mW Zener Diode Through Hole 2-Pin SOD-27 BZX55C6V8-TAP

Vishay BZX55C6V8-TAP is a high-stability 6.8 V Zener diode designed for voltage regulation applications. It belongs to the BZX55 series, offering a maximum power dissipation of 500 mW, suitable for small signal regulation in electronic circuits.

The diode features a single-element chip with a 2-pin through hole mount in the compact SOD-27 package, measuring 3.9 mm in length and 1.7 mm in height. It is engineered for high performance with low reverse leakage current and sharp reverse characteristics, making it ideal for sensitive PCB applications.

This diode is rated for operation in a wide temperature range from -65°C to 175°C, and the automotive-grade AEC-Q101 compliance ensures reliability in harsh automotive and industrial environments.

The device exhibits a typical voltage temperature coefficient of 0.05% per degree Celsius, ensuring voltage stability across temperature variations. Its maximum zener impedance of 8 Ω ensures low noise and high accuracy.

Single diode configuration for precise voltage regulation. Nominal zener voltage of 6.8 V with ±6% tolerance. Maximum power dissipation of 500 milliwatts. 2-pin through hole mounting in SOD-27 package. Wide operating temperature range from -65°C to 175°C.

Extremely low reverse leakage current of 100 nA. Test current of 5 mA ensures stable voltage regulation. Automotive standard AEC-Q101 qualification for reliability. RoHS compliant materials and manufacturing processes.

This Zener diode is suitable for a variety of industrial, automotive, and electronic applications requiring stable voltage references and protective voltage regulation. Its compact form factor enables easy integration in through hole PCB assemblies.
