Omron PCB Signal Relay, 5V DC Coil, 1A Switching Current, DPDT Contact Configuration G6AU-274P-ST-US 5DC

Omron G6AU-274P-ST-US 5DC PCB Signal Relay is a compact and reliable latching relay designed with a 5V DC coil voltage and a double pole double throw (DPDT) contact configuration. It supports a switching current of 1 amp and provides a switching power capacity of 60 watts, making it ideal for various industrial and electronic applications requiring signal switching with precise control.

The relay coil has a resistance of 250 ohms and consumes only 100 milliwatts of power, enabling efficient operation with minimal energy consumption. This makes it suitable for applications requiring low power signal conditioning without compromising performance.

Featuring gold plated contacts, the relay ensures a low contact resistance of 50 milliohms, enhancing electrical conductivity and reducing wear over its operational life. The compact physical size - measuring 20.2mm in length, 10.1mm width, and 8.4mm height - allows it to be mounted directly on printed circuit boards (PCBs) with solder terminals, facilitating easy integration into telecommunications equipment, industrial controls, and automation systems.

Designed to operate reliably in demanding environmental conditions, the G6AU-274P-ST-US 5DC relay withstands operating temperatures ranging from -40°C up to 70°C. It is fully sealed to protect against dust and moisture and complies with RoHS directives, ensuring environmentally friendly usage without hazardous substances.

Manufactured in Japan, this Signal Relay is recognized for its superior build quality and long service life. It is widely used in industrial, telecommunications, and commercial electronic equipment where precise and dependable signal switching is essential.

The relay provides DPDT contact configuration suitable for multiple circuit control. Supports switching AC voltage up to 250V and DC up to 220V. Low coil power consumption of 100mW makes it energy efficient. Gold plated contacts deliver reliable low resistance connectivity.

Compact size and PCB mount type simplify circuit integration. Wide operating temperature range from -40°C to 70°C supports diverse environments. Fully sealed design enhances durability and reliability. RoHS compliant, meeting environmental and safety standards.

Ideal for industrial, telecommunications, and automation applications. Explore more high-quality relays and signal conditioning products in the Electronics & Electricals category at EnvMart for your industrial and laboratory automation needs.
