DiodesZetex NPN Transistor 4 A 50 V 6-Pin SOT-23 Surface Mount ZXT13N50DE6TA
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 0.8mm |
| Length | 3.1mm |
| Model | ZXT13N50DE6TA |
| Width | 3mm |
| Mount Type | Surface |
| Series | ZXTX |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 6 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 10 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 7.5V |
| Maximum Collector Base Voltage VCBO | 100V |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 1.7W |
| Maximum DC Collector Current Idc | 4A |
| Transistor Configuration | Single |
| Maximum Transition Frequency ft | 115MHz |
Key Features
- This transistor supports high current up to 4 amperes for robust applications.
- It features a collector-emitter voltage rating of 50 volts suitable for medium voltage circuits.
- The device includes a 6-pin SOT-23 package optimized for surface mount technology.
- It exhibits a maximum power dissipation of 1.7 watts in typical operating conditions.
- The transistor delivers a minimum DC current gain (hFE) of 10, ensuring effective amplification.
- Operating temperature range from -55°C to 150°C enables use in harsh environments.
- Maximum transition frequency of 115 MHz makes it suitable for high-frequency switching applications.
- Compliance with automotive standard AEC-Q101 ensures automotive grade reliability.
Product Description
DiodesZetex ZXT13N50DE6TA is a general-purpose NPN bipolar transistor designed for a wide range of industrial and automotive electronic applications. The device supports a maximum DC collector current of 4 A and can withstand collector-emitter voltages up to 50 V. Its compact 6-pin SOT-23 package supports surface mounting on printed circuit boards, providing efficient and space-saving integration.
The transistor’s collector-base voltage rating reaches 100 V, and it features a maximum power dissipation of 1.7 W, reflecting its capability in handling moderate power levels. It ensures reliable performance across an operating temperature range from -55°C to 150°C, meeting demanding environmental conditions common in automotive and industrial sectors.
With a minimum DC current gain (hFE) of 10 and a maximum transition frequency of 115 MHz, this transistor performs well in signal amplification and high-speed switching circuits. Its NPN polarity and single transistor configuration make it versatile for various circuit designs.
The ZXT13N50DE6TA complies with the AEC-Q101 automotive standard, certifying its robustness and quality for automotive electronics. The transistor’s compact dimensions, 3.1 mm length, 3 mm width, and 0.8 mm height, support dense PCB layouts and automated assembly.
Supports collector current up to 4 A for robust circuit demands. Rated voltage of 50 V collector-emitter for medium power applications. Compact 6-pin SOT-23 package for surface mount assembly. Maximum power dissipation at 1.7 W ensures adequate thermal tolerance.
Wide temperature range (-55°C to 150°C) suitable for harsh environments. High transition frequency of 115 MHz for high-speed switching tasks. Automotive standard compliance (AEC-Q101) guarantees reliability.
This transistor is widely applicable in industrial control systems, automotive electronics, power management circuits, and general-purpose amplification tasks. It is ideal for engineers and designers seeking a reliable, surface-mount transistor with good power and frequency performance characteristics.
Explore more semiconductor and transistor products in the Electronics & Electricals category at EnvMart for your industrial, automotive, and consumer electronics needs.
Explore more products in our Bipolar Transistors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum DC collector current for this model is 4 A, making it suitable for robust circuit demands.
It has a collector-emitter voltage rating of 50 V, which is appropriate for medium power applications.
This transistor comes in a 6-pin SOT-23 package, optimized for surface mount technology.
The operating temperature range is from -55°C to 150°C, allowing use in harsh environments.
The maximum power dissipation is 1.7 W, which ensures adequate thermal tolerance during operation.
It delivers a minimum DC current gain (hFE) of 10, ensuring effective amplification.
The maximum transition frequency is 115 MHz, making it suitable for high-speed switching applications.
This model complies with the AEC-Q101 automotive standard, ensuring automotive grade reliability.
The dimensions of this model are 3.1 mm in length, 3 mm in width, and 0.8 mm in height.
The maximum collector-base voltage rating is 100 V, providing additional robustness in circuit design.
This transistor features a single transistor configuration, which is versatile for various circuit designs.
The maximum emitter-base voltage (VEBO) rating is 7.5 V, which is important for circuit protection.
