Bourns IP67 White Tactile Switch Push Button 4.8 mm SPST 100mA 16V AC/DC Surface Mount IP67

Bourns 7914G-1-000E is a high-quality IP67-rated white tactile switch push button designed for surface mounting in electronic applications. Featuring a 4.8 mm white push button actuator, the switch supports a single-pole single-throw (SPST) contact configuration with an on-off switch operation.

This switch is sealed to the IP67 standard, offering excellent resistance to dust and water, making it ideal for applications requiring board washing or exposure to challenging environments. It supports both AC and DC voltages up to 16V and a contact current rating of 100mA, suitable for low-power electronic controls.

The compact size, with length of 4.93 mm, width of 4.5 mm, and height of 6.2 mm, allows integration into constrained PCB spaces. The actuator requires an operating force of 300 grams, providing tactile feedback for reliable switching function. Mechanical durability is rated at 500,000 cycles, ensuring long-term operational life.

Operating temperature range is broad, from -55°C low to 125°C high, enabling use in industrial, automotive, and other harsh environment applications. The switch uses solder tab terminals for surface mounting, compatible with most soldering processes.

This component complies with RoHS directives and adheres to EIA/EIAJ/IPC/VRCI SMD standard outline dimensions, supporting quality manufacturing requirements. Sealed for board washing and harsh environment resistance. Compact surface mount design with solder tab terminals.

Reliable push button actuator with tactile response. Wide operating temperature and mechanical life for industrial use. RoHS compliant and meets multiple industry standards.

This Bourns tactile switch is suitable for electronics manufacturing, industrial controls, automotive instrumentation, and consumer device applications. For more quality Bourns products and Tactile Switches, browse EnvMart’s extensive industrial electronics category.
