Infineon 1200 V 8 A Silicon Carbide Schottky Diode 3-Pin TO-247 IDM08G120C5XTMA1

Infineon IDM08G120C5XTMA1 is a state-of-the-art Silicon Carbide (SiC) Schottky diode designed for demanding electronic applications requiring high voltage and current handling capabilities. This diode supports a maximum continuous forward current of 8 A and a peak reverse repetitive voltage of 1200 V, making it suitable for power electronics, industrial, automotive, and renewable energy applications.

Utilizing Infineon's 5th Generation thinQ! technology, this diode offers a low forward voltage of 2.85 V which contributes to high efficiency and reduced power losses in systems. The diode's construction ensures no reverse recovery charge and a mild positive temperature coefficient, enhancing system reliability and thermal management in various operating conditions. With a peak non-repetitive forward surge current rating of 70 A, it offers excellent surge current capability for demanding transient conditions.

This device operates reliably in extreme environments with an operating temperature range from -55°C to 175°C. Its TO-247 3-pin package aids in efficient heat dissipation and ease of mounting in power modules.

Typical applications include industrial motor drives, power supplies, solar inverters, and battery management systems. The diode complies with JEDEC standards, assuring quality and performance consistency.

Maximum continuous forward current of 8 amperes ensures suitability for moderate power applications. High blocking voltage of 1200 volts provides robustness in high voltage circuits. Advanced 5th Generation thinQ! technology delivers improved efficiency and reliability.

Low forward voltage drop reduces conduction losses and enhances thermal performance. Excellent surge current capacity at 70 amperes supports high transient loads. Wide operating temperature range of -55°C to 175°C for harsh environments.

Compact TO-247 3-pin package for easy integration and effective heat dissipation. Complies with JEDEC standards ensuring quality and reliability.

This Silicon Carbide Schottky diode from Infineon is optimized for demanding power electronics tasks in industrial, automotive, and renewable sectors. Its robust specifications make it an ideal choice for efficiency-focused applications requiring reliability and compact form factor. Discover more semiconductor components and power diodes on EnvMart to suit your industrial and commercial needs.
