Microchip Operational Amplifier, Gain Bandwidth Product 10 MHz, 5-Pin SC-70-5, 5.5V MCP6V99-E/ST

Microchip MCP6V99-E/ST is a high-performance operational amplifier designed for demanding analog applications requiring high precision and stability. Featuring a gain bandwidth product of 10 MHz, this device supports rapid signal processing and amplification with excellent linearity. It comes in a compact 5-pin SC-70-5 surface mount package, making it ideal for space-constrained PCB layouts.

The amplifier incorporates zero-drift technology to minimize input offset voltage and drift, achieving a maximum offset of just 25 μV and an offset drift of 150 nV/°C, which ensures stable performance over temperature variations. The input bias current is ultra-low at 50 pA, reducing signal measurement errors, and the slew rate of 9.5 V/μs enables fast response to signal transitions.

This operational amplifier provides an output current of up to 30 mA and is unity gain stable without the presence of 1/f noise, which enhances signal integrity for precision instrumentation and sensor interfaces. Its enhanced EMI rejection design helps maintain signal fidelity in electrically noisy environments.

The package dimensions are 5.1 mm in length, 6.4 mm in width, and 1.2 mm in height, suitable for surface mounting on compact electronic devices. The MCP6V99 series is widely adopted in industrial, laboratory, instrumentation, communications, and automotive applications (note that this particular model is not certified under automotive standards).

By combining low offset voltage, low noise, and high speed, the MCP6V99-E/ST operational amplifier supports precision electronic designs requiring long-term stability and reliability. It is suitable for applications such as sensor signal conditioning, medical instrumentation, and industrial automation controls.

Offers very low input offset voltage of 25 μV for precision applications. Includes ultra-low input bias current of 50 pA for minimal signal distortion. Provides a high slew rate of 9.5 V/μs to handle rapid signal changes.

Output current capability up to 30 mA suitable for driving loads. Designed with enhanced EMI rejection and zero-drift input offset correction. Compact SC-70-5 surface mount package with dimensions 5.1x6.4x1.2 mm. Unity gain stable operational amplifier free of 1/f noise.

Single-channel configuration for versatile use. Ideal for industrial, laboratory, instrumentation, and communication systems. Not automotive standard certified. Explore additional Operational Amplifiers and semiconductor components within the Microchip product range at EnvMart for diverse electronic design needs.
