Vishay Surface-Mount 60 V 5 A Schottky Rectifier Diode 2-Pin DO-221AC VSSAF5M6HM3/H
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1mm |
| Length | 5.35mm |
| Model | VSSAF5M6HM3/H |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | VSSAF5M6 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-221AC |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS and AEC-Q101, JESD 201 Class 2 whisker test |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 5A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 350μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.66V |
Key Features
- The diode features a 2-pin DO-221AC package suitable for surface mounting.
- Maximum continuous forward current is 5A with a peak reverse repetitive voltage of 60 V.
- Utilizes trench MOS Schottky technology for low forward voltage drop of 0.66 V.
- Operates within a temperature range of -40°C to 175°C.
- Peak non-repetitive forward surge current is rated up to 100 A.
- Meets automotive standard AEC-Q101 and RoHS compliance.
- Compact dimensions of 5.35 mm length, 2.7 mm width, and 1 mm height enable low-profile applications.
- Ideal for use in low voltage, high frequency inverters, freewheeling, DC/DC converters, and polarity protection in commercial, industrial, and automotive sectors.
Product Description
Vishay VSSAF5M6HM3/H is a high-efficiency Schottky rectifier diode in a low-profile DO-221AC 2-pin surface-mount package. Rated for 60 V peak reverse repetitive voltage and 5 A continuous forward current, it leverages advanced trench MOS Schottky technology to deliver very low forward voltage drop (0.66 V) and minimal power losses.
This diode supports operation over a wide temperature range from -40°C to 175°C and maintains reliability and performance in automotive environments, being qualified to AEC-Q101 standards along with RoHS and JESD 201 Class 2 whisker testing.
Its compact physical size (5.35 mm length, 2.7 mm width, 1 mm height) and surface-mount design make it ideal for automated PCB assembly in demanding power conversion and protection circuits.
Common applications include use in low voltage, high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection in commercial, industrial, and automotive electronic devices.
The diode features trench MOS Schottky technology delivering low forward voltage drop for efficient operation. Designed to handle peak non-repetitive forward surge currents of 100 A safely. Compliance with automotive standards ensures reliability in rugged conditions.
Surface-mount DO-221AC package supports automated manufacturing processes. Compact dimension allows integration into space-constrained designs. RoHS compliant and tested for whisker growth, ensuring environmental and reliability standards.
Suitable for a wide range of industrial, commercial, and automotive power electronic applications.
Explore additional Vishay semiconductor components and Schottky Diode solutions in the Electronics & Electricals category on EnvMart to find suitable products for your industrial and commercial electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current is 5 A.
The peak reverse repetitive voltage rating is 60 V.
The dimensions are 5.35 mm in length, 2.7 mm in width, and 1 mm in height.
It operates within a temperature range of -40°C to 175°C.
The maximum forward voltage drop is 0.66 V.
The peak non-repetitive forward surge current is rated up to 100 A.
It meets automotive standard AEC-Q101 and is RoHS compliant.
The diode comes in a DO-221AC package suitable for surface mounting.
This diode has a 2-pin configuration.
It is suitable for low voltage, high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection in various sectors.
The country of origin for this diode is India.
This is a Schottky rectifier diode, specifically a single diode configuration.
