RS PRO HMI Panel 7 Inch Entry Level TFT LCD Display 800 x 480 Pixel with 2 Ports RS422/485, COM, RS232, USB 2.0 215-6604

Free Delivery in India | Lowest Global Shipping Charges

RS PRO HMI Panel 7 Inch Entry Level TFT LCD Display 800 x 480 Pixel with 2 Ports RS422/485, COM, RS232, USB 2.0 215-6604

Name: RS PRO HMI Panel 7 Inch Entry Level TFT LCD Display 800 x 480 Pixel with 2 Ports RS422/485, COM, RS232, USB 2.0 215-6604
Brand: RS PRO
SKU: 287871
Price: 336.25 USD
Availability: InStock



Category HMI Panel Brand RS PRO Condition New

Specifications

Country of Origin	China
Display Type	TFT LCD
Display	7in colour display
Brand	RS PRO
Operating Temperature	-10 °C to 60 °C
Interface	USB/ Ethernet
Length	201.2mm
Memory	128M FLASH, 128M DDRAM
Model	215-6604
Depth	39mm
IP Rating	IP65
Width	201mm
Series	RS PRO
Number Of Ports	2
Display Resolution	800 x 480 pixel
Maximum Operating Temperature	60°C
Port Type	RS422/485, COM, RS232, USB 2.0
Minimum Operating Temperature	-10°C
Standards/Approvals	CE, RoHS
RS stock no	215-6604
Onboard Memory	128MB
Diagonal Display Size	177.8mm

Key Features

Features a 7 inch colour TFT LCD display with 800 x 480 pixel resolution.
Two communication ports supporting RS422/485, COM, RS232, and USB 2.0 interfaces.
Equipped with 128MB onboard FLASH and DDRAM memory for efficient processing.
Operates in a temperature range from -10°C to 60°C with IP65 rated waterproof protection.
Powered by a Cortex A7 processor for fast boot time and fluent touchscreen response.
Ideal for industrial and commercial environments including process control and information systems.
Compact dimensions measuring 201.2 x 201 x 39 mm for easy panel mounting.
Complies with CE and RoHS standards assuring quality and safety.

Product Description

RS PRO 2156604 is a 7 inch HMI Panel featuring an entry level TFT LCD display with a resolution of 800 x 480 pixels. This touch-screen Human Machine Interface panel is designed to enhance machine monitoring and control in industrial settings, providing quick boot-time, responsive touchscreen operation, and excellent communication stability via its dual RS422/485, COM, RS232, and USB 2.0 ports.

The device encompasses 128MB of FLASH and DDRAM memory, powered by a Cortex A7 processor delivering efficient, high-performance operation suitable for visualization tasks and control applications. It operates reliably within a temperature range from -10°C to 60°C, and its IP65 rating ensures protection against dust and water ingress, making it suitable for harsh industrial and commercial environments.

The panel dimensions are 201.2 mm length, 201 mm width, and 39 mm depth, facilitating convenient panel mounting. Compliant with CE and RoHS standards, this HMI panel provides a trusted solution for process control systems, information solutions, air traffic control, and more.

7 inch colour TFT LCD display with 800 x 480 pixel resolution. Two ports including RS422/485, COM, RS232, and USB 2.0 interfaces for versatile communication. 128MB onboard FLASH and DDRAM memory for enhanced software capabilities.

Operating temperature range from -10°C to 60°C with IP65 waterproof rating. Fast and fluent touchscreen control powered by Cortex A7 processor. Compact size ideal for panel mounting in industrial environments. Complies with CE and RoHS standards ensuring quality and safety.

This RS PRO HMI Panel is suitable for use in industrial automation applications, commercial environments, process control, air-traffic control, and other scenarios requiring stable and efficient human-machine interactions. Explore the full RS PRO HMI Displays range at EnvMart for comprehensive automation solutions.
