STMicroelectronics N-Channel Array Smart Power Module 15A 600V 26-Pin SDIP2B Through Hole STGIB10CH60TS-L
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 3.5mm |
| Length | 38mm |
| Model | STGIB10CH60TS-L |
| Width | 24mm |
| Mount Type | Through Hole |
| Configuration | Array |
| Maximum Operating Temperature | 125°C |
| Package Type | SDIP2B |
| Minimum Operating Temperature | -40°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 917-3378Brand: STMicroelectronicsManufacturers Part No.: STGIB10CH60TS-L |
| Pin Count | 26 |
| Maximum Continuous Collector Current Ic | 15A |
| Maximum Collector Emitter Voltage Vceo | 600V |
| Maximum Collector Emitter Saturation Voltage VceSAT | 1.95V |
| Channel Type | N |
| Maximum Power Dissipation Pd | 66W |
| Number of Transistors | 6 |
Key Features
- The module features 6 transistors configured in an array for efficient power management.
- It supports through-hole mounting suitable for durable industrial applications.
- Maximum power dissipation is rated at 66W for robust performance.
- Designed for operation between -40°C and 125°C for wide environmental compatibility.
- Low voltage saturation of 1.95V ensures energy-efficient switching.
- Compact dimensions of 38mm length, 24mm width, and 3.5mm height fit tight PCB layouts.
- Includes intelligent power modules technology suitable for motor drive applications up to 20 kHz switching frequency.
- Features built-in control ICs for gate driving, undervoltage lockout, and fault protection.
Product Description
STMicroelectronics STGIB10CH60TS-L is an advanced N-Channel Array Smart Power Module designed for efficient motor drive and power control applications. It integrates 6 transistors in a compact 26-pin SDIP2B through-hole package, delivering a maximum continuous collector current of 15A and collector-emitter voltage of 600V.
This module supports operation in harsh industrial environments with a wide temperature range from -40°C to 125°C and a power dissipation capacity of 66W. It features a low collector-emitter saturation voltage of 1.95V, enabling reduced conduction losses and enhanced energy efficiency.
The STGIB10CH60TS-L employs STMicroelectronics' proprietary SLLIMM™ Intelligent Power Module technology. It includes optimized gate drivers, low electromagnetic interference design, and a rugged DBC-based packaging for improved thermal performance.
Applications include industrial motor controllers, HVAC systems, and other motor drive solutions requiring high efficiency at switching frequencies up to 20 kHz. The module provides smart functionalities such as undervoltage lockout, open emitter outputs, interlocking, smart shutdown, and built-in fault protection against over temperature and overcurrent conditions.
Dimensions of 38mm by 24mm and 3.5mm thickness allow integration in dense PCB designs. The module's through-hole mounting facilitates reliable and serviceable installation in industrial electronic assemblies.
The module includes 6 transistors configured as an array for scalable power output. It operates reliably under temperatures ranging from -40°C to 125°C. Maximum power dissipation is 66W, supporting demanding industrial workloads.
Optimized for motor drive applications up to 20 kHz switching frequencies. Incorporates safety features such as electrical isolation at 1500 Vrms/min. Smart functions include fault protection, undervoltage lockout, and internal bootstrap diode.
Compact SDIP2B 26-pin package suitable for through-hole mounting.
This smart power module is ideal for applications in industrial automation, HVAC equipment, and power electronics where efficiency and reliability are paramount. Explore the full range of STMicroelectronics IGBT Modules on EnvMart for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous collector current of the STGIB10CH60TS-L is 15A.
This module has a collector-emitter voltage rating of 600V.
The maximum power dissipation capacity is rated at 66W.
It operates reliably within a temperature range of -40°C to 125°C.
The dimensions of the STGIB10CH60TS-L are 38mm in length, 24mm in width, and 3.5mm in height.
This model supports through-hole mounting, suitable for durable industrial applications.
The STGIB10CH60TS-L integrates 6 transistors configured in an array.
The maximum collector-emitter saturation voltage is 1.95V.
It is designed for motor drive applications, including industrial motor controllers and HVAC systems, operating at switching frequencies up to 20 kHz.
The module includes safety features such as undervoltage lockout, fault protection against over temperature and overcurrent, and an internal bootstrap diode.
It uses a compact 26-pin SDIP2B package type.
It employs STMicroelectronics' proprietary SLLIMM™ Intelligent Power Module technology for optimized performance.
