Key Instruments Series Variable Area Flow Meter for Gas 0.1L/min to 1L/min, Acrylic Housing, 6.89 bar Max Pressure FR2000

Category Flow Meter Brand Key Instruments Condition New

Specifications

Country of Origin United States
Brand Key Instruments
Model FR2000
Connection Type 1/8 in NPT Female
Housing Material Acrylic
Series FR2000
Maximum Pressure 6.89bar
Minimum Flow Rate 0.1L/min
Minimum Operating Temperature 65°C
Device Type Variable Area
Maximum Flow Rate 1L/min
Media Monitored Gas
Maximum Media Temperature 65°C
BROOKS GR Series Flow Meter 0.5L/min to 5L/minBrand BROOKS
RS PRO Air Flow Sensor for Air, 0.1L/min Min, 1L/min MaxRS Stock No. 257-6410Brand: RS PRO

Key Features

  • The meter has a durable one-piece acrylic housing for clear visibility.
  • It allows direct reading of gas flow rate on English or metric scales.
  • Maximum operating temperature is 65°C suitable for various applications.
  • Rod guided float enables stable and repeatable measurements.
  • Includes fittings and Buna-N O-rings ideal for multiple installation scenarios.
  • Valve with positive stop maintains set flow pressure without slippage.
  • Easy to disassemble and maintain for long-term reliability.
  • Primarily designed for low-pressure, non-corrosive gas flow monitoring.

Product Description

Key Instruments FR2000 Series Variable Area Flow Meter for Gas is a precision-machined device designed to accurately measure gas flows ranging from 0.1L/min minimum to 1L/min maximum. This flow meter features a robust one-piece acrylic housing that provides excellent visibility of the internal float and scale. The variable area mechanism offers reliable, direct-reading scales available in English or metric units for flexibility in different measurement settings.

Constructed with brass fittings and Buna-N O-rings, the FR2000 ensures durability and compatibility with a variety of low-pressure, non-corrosive gases. The meter supports a maximum operating pressure of 6.89 bar and a media temperature up to 65°C, making it suitable for diverse industrial and laboratory environments.

The valve integrated with the unit includes a positive stop feature to maintain consistent flow rates under pressure. The rod-guided float ensures stable and repeatable measurements, crucial for air sampling, gas analysis, and water treatment process control.

Maintenance is straightforward due to the easy disassembly and assembly design, allowing minimal downtime. The FR2000 Flow Meter is ideal for use in air sampling equipment, aquaculture, desalinisation plants, medical systems, photo processing, and gas analyser setups.

The meter offers easy installation with 1/8 inch NPT female connection compatible with standard piping. High durability acrylic body withstands demanding project conditions and mounting panel requirements. Perfect for low-pressure, non-corrosive air, water, or gas flow applications requiring precision.

Clear, large scales enable quick on-site flow rate assessments without additional instrumentation. Manufactured in the United States, ensuring quality compliance and reliability. Explore the Key Instruments category on EnvMart for more precision flow measurement solutions and accessories optimized for industrial use.

Key Instruments Series Variable Area Flow Meter for Gas 0.1L/min to 1L/min, Acrylic Housing, 6.89 bar Max Pressure FR2000
Looking to purchase in bulk?
  • Purchase item in bulk quantity
  • Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The FR2000 flow meter measures gas flows ranging from a minimum of 0.1L/min to a maximum of 1L/min.

This model has a maximum operating pressure of 6.89 bar, suitable for low-pressure applications.

The flow meter features a one-piece acrylic housing, brass fittings, and Buna-N O-rings, ensuring compatibility with non-corrosive gases.

This unit uses a 1/8 inch NPT female connection, compatible with standard piping systems.

The FR2000 can operate at a maximum media temperature of 65°C.

The integrated valve features a positive stop that helps maintain set flow pressure without slippage.

It is suitable for applications such as air sampling, gas analysis, aquaculture, and medical systems.

The flow meter is designed for easy disassembly and assembly, allowing for straightforward maintenance and minimal downtime.

This model utilizes a rod-guided float mechanism, which ensures stable and repeatable measurements.

The FR2000 is manufactured in the United States, ensuring compliance with quality standards.

The flow meter features direct-reading scales available in both English and metric units for flexible measurement options.
