STMicroelectronics Surface Mount 3-Pin TRIAC 800 V 25A TO-263 Package T2535-800G-TR
Specifications
| Country of Origin | China |
|---|---|
| Brand | STMicroelectronics |
| Height | 4.6mm |
| Length | 10.28mm |
| Model | T2535-800G-TR |
| Mount Type | Surface |
| Configuration | Single |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 25A |
| Repetitive Peak Reverse Voltage VDRM | 800V |
| Surge Current Rating | 250A |
| Maximum Gate Trigger Current Igt | 35mA |
| Maximum Holding Current Ih | 50mA |
| Maximum Gate Trigger Voltage Vgt | 1.3V |
| Peak Gate Power Dissipation | 1W |
Key Features
- Rated average on-state current of 25A provides robust switching capability.
- Surface mount design with TO-263 package for easy PCB integration.
- Maximum repetitive peak reverse voltage of 800 V ensures reliable operation.
- Gate trigger voltage of 1.3 V enables precise control of activation.
- Maximum gate trigger current of 35mA for effective triggering.
- Surge current rating of 250A allows handling transient surges safely.
- Wide operating temperature range from -40°C to 125°C suits diverse environments.
- Compact dimensions of 10.28mm length and 4.6mm height for space-saving designs.
Product Description
STMicroelectronics T2535-800G-TR is a high-performance surface mount TRIAC specially engineered for AC power control and switching in industrial, commercial, and consumer electronic circuits. With a robust average on-state current rating of 25A and a repetitive peak reverse voltage of 800V, this device guarantees safe and reliable switching of electrical loads.
The TRIAC features a TO-263 package type with a compact form factor of 10.28mm length and 4.6mm height, making it suitable for integration in space-constrained PCB layouts. Its gate trigger parameters, including a maximum gate trigger voltage of 1.3 V and gate trigger current of 35 mA, ensure precise control and efficient switching performance.
This component supports surge currents up to 250 A, accommodating transient electrical conditions encountered in industrial and automation systems. The wide operating temperature range from -40°C to 125°C allows this TRIAC to function effectively in harsh environments.
Compliance with RoHS standards confirms that the T2535-800G-TR meets environmental and safety regulations, making it suitable for contemporary electronic manufacturing.
Typical applications of this TRIAC include motor control, lighting dimmers, heater controls, and other AC load switching tasks in industrial automation, HVAC systems, and consumer appliances.
Rated average on-state current of 25A. Surface mount TO-263 package. Maximum repetitive peak reverse voltage of 800 V. Gate trigger voltage max 1.3 V with 35 mA current. Surge current handling of 250 A. Wide temperature range (-40°C to 125°C).
Compact dimensions: 10.28mm x 4.6mm. RoHS compliant. 3-pin single configuration suitable for various control circuits. Explore more semiconductor components and TRIACs at EnvMart for your industrial and electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated average on-state current of this TRIAC is 25A, providing robust switching capability for various applications.
The maximum repetitive peak reverse voltage is 800V, ensuring reliable operation in electrical circuits.
The dimensions of the TO-263 package are 10.28mm in length and 4.6mm in height, making it suitable for space-constrained designs.
The maximum gate trigger voltage is 1.3V, and the maximum gate trigger current is 35mA for effective triggering of the TRIAC.
This TRIAC has a surge current rating of 250A, allowing it to handle transient surges safely in various applications.
The operating temperature range for this TRIAC is from -40°C to 125°C, making it suitable for diverse environments.
This model features a surface mount design, facilitating easy integration onto printed circuit boards (PCBs).
The TRIAC has a single configuration with 3 pins, suitable for various control circuits.
Yes, this TRIAC is RoHS compliant, meeting environmental and safety regulations for electronic manufacturing.
Typical applications include motor control, lighting dimmers, heater controls, and AC load switching in industrial automation and consumer appliances.
The maximum holding current for this TRIAC is 50mA, which is relevant for its operation in control circuits.
The peak gate power dissipation for this TRIAC is 1W, which is important for its triggering performance.
