MEAN WELL 600W 48V DC Switching Power Supply Chassis Mount HEP-600-48
Specifications
| Country of Origin | India |
|---|---|
| Brand | MEAN WELL |
| Power | 600W |
| Efficiency | 96% |
| Length | 280mm |
| Model | HEP-600-48 |
| Depth | 48.5mm |
| Gross Weight | 3.76kg |
| Width | 144mm |
| Mount Type | Chassis |
| Series | HEP-600 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 264V |
| Protections | Short circuit / Over current / Over voltage/ Over temperature |
| Standards/Approvals | ASNZS 668.1, EAC TP TC 004, TUV BS ENEN 6681, UL 6681 |
| Maximum Output Voltage | 48V dc |
| SMPS Output Current | 12.5A |
| Minimum Input Voltage | 90V ac |
Key Features
- High power output of 600 watts with an output voltage of 48V DC.
- Chassis mount design suitable for industrial installation.
- Wide input voltage range from 90 to 264V AC for universal compatibility.
- Operating temperature range from -40°C to 70°C ideal for harsh environments.
- High efficiency of up to 96% for energy-efficient operation.
- Fanless design cooled by free air convection for silent operation and reliability.
- Includes built-in active PFC for improved power factor and reduced electrical noise.
- Full protections against short circuit, over current, over voltage, and over temperature.
Product Description
MEAN WELL HEP-600-48 is a high-efficiency 600 watt switching power supply delivering 48V DC output designed for industrial and outdoor applications. This chassis mount power supply features a wide AC input range from 90V to 264V, enabling versatile use worldwide with stable performance. Its robust aluminum enclosure is fully potted with heat-conductive silicone glue, ensuring excellent waterproofing and mechanical reliability.
The power supply boasts an impressive efficiency of up to 96%, minimizing energy loss and heat generation, which allows for fanless, convection cooling. Operating reliably in temperature ranges from -40 degrees Celsius to +70 degrees Celsius, it suits harsh industrial environments including telecommunications, signage, manufacturing, and outdoor equipment.
Safety is a prime focus with multiple protection circuits including short circuit, over current, over voltage, and over temperature safeguards to protect connected devices and ensure operational safety. An LED indicator allows easy visual confirmation of power status. The built-in active power factor correction improves electrical efficiency and reduces interference.
Certified to global standards such as UL60950-1, TUV EN60950-1, ASNZS 668.1, and others, the HEP-600-48 power supply meets stringent safety and reliability requirements. Its resilient construction and high-grade electrical design support long-term, maintenance-free operation in industrial, laboratory, and commercial environments.
This product is an ideal choice for engineers and technicians seeking a dependable, energy-efficient switching power supply for demanding electrical equipment requiring 48V DC at 12.5A output current.
High power output of 600 watts at 48V DC for demanding industrial applications. Wide input voltage range for global usage and flexible deployment. Fanless cooling through convection reduces noise and increases reliability.
Durable aluminum casing fully potted for waterproof and vibration resistance. Multiple protection features ensure safe and stable operation. Suitable for telecommunications, signage, machine control, and outdoor use. Explore the extensive range of MEAN WELL Switching Power Supplies and components at EnvMart for reliable power solutions tailored to your application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 600 watts.
This power supply has an efficiency of up to 96%.
The input voltage range is from 90V to 264V AC.
It operates within a temperature range of -40°C to +70°C.
It includes protections against short circuit, over current, over voltage, and over temperature.
The dimensions are 280mm in length, 144mm in width, and 48.5mm in depth.
The gross weight of this power supply is 3.76kg.
It features a chassis mount design suitable for industrial installation.
The output current is 12.5A.
It is certified to standards such as ASNZS 668.1, TUV BS EN EN 6681, and UL 6681.
This power supply is suitable for telecommunications, signage, machine control, and outdoor use.
