Schneider Electric Acti9 Miniature Circuit Breaker 1-Pole 4A Type C 230V AC 10 kA Breaking Capacity A9P24604
Specifications
| Country of Origin | France |
|---|---|
| Range | Acti9 |
| Brand | Schneider Electric |
| Height | 85mm |
| Model | A9P24604 |
| Depth | 85mm |
| IP Rating | IP20 |
| Width | 74mm |
| Mount Type | DIN Rail |
| Current Rating | 4A |
| Series | Acti9 iDT40N |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | RoHS, EN IEC 60898-1, EN IEC 60947-2, CE, REACH |
| Rated AC Voltage | 230V |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Rated current is 4 amperes suitable for domestic and industrial installations.
- Type C tripping characteristic protects against current surges of 5 to 10 times rated current.
- Mounts easily on DIN rails for quick installation and maintenance.
- Screw terminal type ensures secure and reliable electrical connections.
- VisiSafe green strip indicates safe contact position during maintenance.
- VisiTrip technology visually signals a tripped circuit for faster fault identification.
- Thermal magnetic tripping mechanism offers combined protection from overload and short circuits.
- Padlocking feature prevents accidental or unauthorized switching for safety during maintenance.
Product Description
Schneider Electric A9P24604 Miniature Circuit Breaker is designed for use in industrial, commercial, and domestic electrical distribution systems, providing dependable protection against overload and short circuits at 230V AC operation. This 1-pole device is rated for 4 amperes with a Type C tripping curve, ideal for installations with high surge loads such as fluorescent lighting, small transformers, or pilot devices.
Its DIN rail mounting facilitates quick and tool-less installation while the screw terminals provide firm and reliable cable connections. The built-in VisiSafe green strip clearly indicates safe contact positions for maintenance personnel, while VisiTrip technology offers a visible trip status for easier reset and fault clearance.
The thermal magnetic tripping mechanism combines overload and short-circuit protection with high breaking capacity of 10 kA, assuring operational safety and compliance with international standards including EN IEC 60898-1 and EN IEC 60947-2. Moreover, the device features an IP20 rating, suitable for indoor electrical panels and control boards.
This circuit breaker also integrates a padlocking device, allowing the breaker to be locked in the off position to protect workers during electrical service by preventing unauthorized re-energization.
With physical dimensions of 85mm height, 74mm width, and 85mm depth, it fits neatly into compact electrical panels. Originating from France, the Acti9 series is known for reliability and safety in electrical protection applications.
Rated for 4A current with Type C trip characteristics. DIN rail mount with screw terminals for easy installation. VisiSafe and VisiTrip technologies enhance operational safety. Thermal magnetic trip mechanism with 10 kA breaking capacity.
Padlocking provision for safe maintenance lockout. Compact size with IP20 rated enclosure. Standards compliant including RoHS and CE certification.
Choose Schneider Electric Acti9 A9P24604 for secure, standards-compliant circuit protection in residential, commercial, and light industrial electrical distribution. Explore more circuit breakers and related products at EnvMart for comprehensive electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated current of this model is 4 amperes, suitable for both domestic and industrial installations.
It features a Type C tripping characteristic, which protects against current surges of 5 to 10 times the rated current.
This circuit breaker has a breaking capacity of 10 kA, ensuring effective protection against overloads and short circuits.
It mounts easily on DIN rails, facilitating quick installation and maintenance without the need for additional tools.
It uses screw terminals, which provide secure and reliable electrical connections.
The device has an IP20 rating, making it suitable for use in indoor electrical panels and control boards.
The dimensions are 85mm in height, 74mm in width, and 85mm in depth, allowing it to fit neatly into compact electrical panels.
It includes VisiSafe technology for indicating safe contact positions and VisiTrip technology for visual trip status, enhancing operational safety.
It complies with RoHS, CE, EN IEC 60898-1, and EN IEC 60947-2 standards, ensuring safety and reliability in electrical applications.
It employs a thermal magnetic tripping mechanism, providing combined protection from overload and short circuits.
Yes, this model includes a padlocking feature that prevents accidental or unauthorized switching during maintenance work.
This circuit breaker is manufactured in France, ensuring compliance with international standards and quality assurance.
