Schneider Electric Acti9 iDT40T Miniature Circuit Breaker, 1-Pole, 25A, Type C, 230V AC, 6 kA Breaking Capacity A9P22625

Schneider Electric A9P22625 Miniature Circuit Breaker 1-Pole, 25A, Type C, 230V AC, with 6 kA breaking capacity is engineered for effective protection of electrical circuits in industrial and commercial environments. It safeguards installations against both short-circuit currents and overload conditions while also protecting personnel from indirect contact in TN and IT neutral systems.

This MCB is part of the Acti9 iDT40T series, known for multi-standard compliance, fully tested and certified according to IEC/EN 60898 and IEC/EN 60947-2 standards. The device features a thermal magnetic tripping mechanism allowing fast interruption of fault currents.

The toggle switch reset actuator is equipped with a VisiTrip red indicator window to visually signal fault tripping, facilitating rapid fault detection and troubleshooting to minimize downtime. The green VisiSafe strip ensures the downstream circuit is safe regardless of overvoltage conditions.

Terminals are insulated (IP20) to enhance safety with screw terminals providing robust connections with twice the standard tightening torque. The product’s compact size of 85 mm height, 74 mm width, and 85 mm depth allows easy integration within electrical panels mounted on DIN rails.

Designed for high inductive load applications where switching surges are considerable, the Type C tripping curve offers protection up to 5 to 10 times the rated current, making it suitable for various industrial needs. This miniature circuit breaker is suitable for use in polluted environments and networks requiring reliable circuit protection.

Reliable circuit protection for industrial and commercial electrical systems. Compliance with IEC/EN standards ensures safety and regulatory adherence. Thermal magnetic trip mechanism for effective overload and short circuit protection.

Visual fault indication for fast diagnostics with VisiTrip. Insulated terminals (IP20) for operator safety. DIN rail mounting with robust screw terminals. Compact dimensions optimize panel space. Class-2 insulation protects both operators and unqualified persons.

Manufactured in France ensuring quality and durability. Suitable for high inductive loads with high switching surges.

This Schneider Electric Acti9 iDT40T Miniature Circuit Breaker is ideal for use in industrial automation, commercial buildings, and electrical distribution systems requiring high-quality protective devices. Available through EnvMart’s comprehensive electronics and electricals catalog, it integrates seamlessly into existing systems with guaranteed safety and performance.
