KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD3-35M

Free Delivery in India | Lowest Global Shipping Charges

KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD3-35M

Name: KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD3-35M
Brand: KEMET
SKU: 260168
Price: 730.82 INR
Availability: InStock



Category Reed Switch Brand KEMET Condition New

Specifications

Country of Origin	Japan
Brand	KEMET
Length	27mm
Model	OHD3-35M
Depth	12.5mm
Width	13.5mm
Mount Type	Through Hole
Contact Material	Nickel Iron Alloy
Series	OHD
Maximum Switching Current	300mA
Maximum Operating Temperature	150°C
Contact Configuration	SPST
Minimum Operating Temperature	-20°C
Terminal type	Tab Leads
Contact Resistance	150mΩ
Maximum Switching Power	6W
Standards/Approvals	RoHS
Maximum Switching Voltage	110V ac/dc

Key Features

High reliability for on/off operations in electrical applications.
Compact and lightweight through hole mount design.
Contact material made from nickel iron alloy ensuring durability.
Operating temperature range from -20°C to 150°C.
Low contact resistance of 150 milliohms for efficient switching.
Compatible with low power signals starting from 0.1 mW to 6 W maximum switching power.
Designed for thermal problem countermeasures with unique Thermorite® material.
Applications include atmospheric temperature detection, power modules monitoring, motors, HDDs, amplifiers, and general appliances.

Product Description

KEMET OHD3-35M SPST Through Hole Reed Switch rated at 300 mA with 110 V AC/DC maximum switching voltage, designed for reliable switching operations in various electrical and automation systems.

This switch features high operational reliability, a compact form factor with through hole mounting, and contact material made from nickel iron alloy, which ensures durability and excellent electrical performance.

The device has a low contact resistance of 150 milliohms and supports a wide temperature range from -20°C to 150°C, making it suitable for harsh industrial environments.

The OHD3-35M incorporates a thermal guard using Thermorite®, a temperature-sensitive ferromagnetic substance that changes its magnetic properties at the Curie temperature, offering advanced thermal problem countermeasures.

With a maximum switching power of 6 watts, this reed switch supports signals ranging from extremely low power of 0.1 mW in sensitive applications to higher power levels up to 6 W, facilitating versatile circuit designs.

Typical applications include temperature detection for atmospheric conditions, overheating monitoring in power transistors, power modules, room and hot gas heaters, motors, hard disk drives (HDDs), floppy disk drives (FDDs), amplifiers, and other electrical appliances requiring reliable switching.

The switch’s small dimensions (27 mm length, 13.5 mm width, 12.5 mm depth) contribute to its easy handling and integration in compact layouts. High reliability with long operational life in on/off applications. Compact through hole mounting for easy PCB integration.

Robust nickel iron alloy contacts ensure consistent electrical performance. Wide operating temperature range suited for multiple industrial environments. Low contact resistance improves efficiency. Advanced thermal protection using proprietary Thermorite® technology.

Supports wide power range from 0.1 mW to 6 W. Applications in temperature detection and monitoring of various electrical equipment. RoHS compliant and made in Japan. Explore more in the Reed Switch category on EnvMart for reliable switching solutions tailored to your industrial and automation needs.
