Ewellix Makers in Motion Linear Guide Carriage LLTHC 30 R T0 P5 Series 26.1 kN Dynamic Load LLTHC 30 R T0 P5

Ewellix Makers in Motion LLTHC 30 R T0 P5 Linear Guide Carriage is a precision-engineered linear motion component designed for industrial and mechanical applications requiring reliable and smooth guiding performance. Featuring a dynamic load rating of 26.1 kN, this carriage suits demanding uses in automation, manufacturing, and assembly systems.

The carriage length of 100.4 mm and width of 60 mm provide a compact footprint while supporting a robust load capacity. It accepts rails with a width of 30 mm, offering compatibility with various linear motion rails.

This model integrates side and inner seals as a standard feature, minimizing contamination ingress and enhancing durability. The carriage's slim-line design is complemented by an extended height that improves rigidity and load distribution.

The product has undergone precision grinding to ensure low roughness on rail surfaces, which contributes to its smooth running and low friction characteristics. It is built to support equal load distribution with top rigidity, making it ideal for applications where stable and precise motion is critical.

Installation is streamlined by four threaded mounting holes placed on the top side of the carriage, facilitating secure and easy attachment. Produced in Taiwan, Province Of China, this linear guide carriage meets quality standards typical of high-performance industrial components.

The carriage measures 100.4 mm in length and 60 mm in width. It supports a dynamic load rating of 26.1 kN for heavy-duty applications. Accepts 30 mm wide rails compatible with standard linear guides. Includes integrated seals for dust protection and maintenance reduction.

Features a slim-line design with extended height to increase rigidity. Equipped with four threaded mounting holes for secure installation. Manufactured with precision grinding for low surface roughness and friction.

This linear guide carriage is commonly utilized in industrial automation, manufacturing machinery, assembly lines, and other mechanical systems requiring efficient and accurate linear motion solutions. Its robust design and quality manufacturing make it a reliable choice for critical mechanical applications.
