Ewellix Makers in Motion Linear Guide Carriage 20mm Rail Width, 9.24 kN Dynamic Load LLTHC 20 SU T0 P5

Ewellix Makers in Motion LLTHC 20 SU T0 P5 Linear Guide Carriage features a carriage length of 55.4 mm and width of 44 mm, designed for high-precision linear motion tasks requiring a dynamic load capacity of 9.24 kN and static load capacity of 14.4 kN. Manufactured in Taiwan, Province Of China, this component delivers reliable and efficient performance for industrial automation, manufacturing, robotics, and other mechanical applications.

The carriage benefits from integrated side and inner seals that safeguard internal components from contaminants. It provides equal load carrying capacity with enhanced rigidity on top, ensuring stable guidance under loads. Dual reference sides on rails allow precise positioning and reduce play during motion cycles. The rail surface is finely finished with low roughness, minimizing friction and wear and contributing to longer service life.

Designed for ease of installation and adjustment, this linear guide carriage requires minimal maintenance. The model provides a short and slim-line carriage profile with a standard height suitable for various size requirements (15 to 45 mm). It is also equipped with two threaded holes on the top side for convenient mounting.

This linear guide carriage is widely applicable in industrial use cases such as automated machinery, laboratory equipment, fluid power systems, HVAC systems, manufacturing lines, and precision mechanical assemblies requiring smooth and controlled linear movement.

The carriage length measures 55.4 mm ensuring compact design. Carriage width is 44 mm providing robust support. Acceptable rail width is 20 mm optimized for compatibility. Side and inner seals are integrated by standard to enhance protection.

Offers equal load carrying capacity with top rigidity for stable performance. Rails feature dual reference sides for precise alignment and smooth operation. Low surface roughness on rails reduces friction and wear. Easy installation and low maintenance thanks to smooth running on high-quality surfaces.

Short, slim-line carriage with standard height available for sizes 15 to 45. Equipped with two top side mounting threads for secure fixing.

This product is part of EnvMart's Linear Guide Carriage category, ideal for professionals seeking high-quality linear motion components from reputed brands like Ewellix Makers in Motion.
