Ewellix Makers in Motion Linear Guide Carriage LLTHC 15 R T0 P5 Series, 8.4 kN Dynamic Load LLTHC 15 R T0 P5

Ewellix Makers in Motion LLTHC 15 R T0 P5 Linear Guide Carriage is a precision-engineered component designed to deliver high rigidity and dynamic performance in industrial linear motion systems. Rated for a dynamic load of 8.4 kN and a static load rating of 15.4 kN, this carriage supports demanding mechanical and automation applications.

The carriage measures 63.3 mm in length and 34 mm in width, designed to fit acceptable rail widths of 15 mm. With integrated side and inner seals as standard, it protects internal components from contaminants, minimizing wear and maintenance requirements.

This Linear Guide Carriage offers equal load carrying capacity combined with top rigidity, ensuring reliable operation in high precision and load-intensive environments. The rail surfaces are finished with low roughness to reduce friction and support smooth, wear-resistant motion.

The product features a standard slim-line carriage with an extended height to enhance rigidity where space is limited. Ease of installation is facilitated by the provision of four threaded mounting holes on the top side. The design supports various sizes, from 15 mm to 45 mm, providing versatility in industrial machinery setups.

Typical use cases for the LLTHC 15 R T0 P5 include industrial automation, manufacturing equipment, robotics, and other precision motion applications where load capacity and smooth operation are critical.

Integrated side and inner seals for protection. Top rigidity and load capacity. Low friction sliding on high-quality rails. Four mounting threads for easy installation. Standard slim-line design with extended height. Suitable for various sizes within the series range.

Manufactured in Taiwan, Province Of China.
