Ewellix Makers in Motion Linear Guide Carriage , 26.1 kN Dynamic Load, Slimline Carriage, 100.4 mm Length LLTHC 30 U T0 P5

Ewellix Makers in Motion LLTHC 30 U T0 P5 linear guide carriage is a precision mechanical component designed for high-performance linear motion applications. It supports a dynamic load rating of 26.1 kN and static load rating of 41.9 kN, suitable for demanding industrial and manufacturing environments.

This slimline carriage has a length of 100.4 mm and a width of 60 mm, specifically designed to be used with rails of 30 mm acceptable width. The carriage integrates side and inner seals as a standard feature, protecting internal components from contamination and extending service life.

Its construction offers equal load carrying capacity combined with enhanced top rigidity. The dual reference sides of the rails ensure precise alignment, allowing smooth running on high-quality, low-roughness rail surfaces. The design minimizes friction and wear, contributing to operational reliability and reduced maintenance frequency.

Installation is simplified by the carriage's four threaded mounting holes accessible from the top side, making adjustments straightforward and maintenance minimal. This standard length, slimline carriage ranges from sizes 15 to 45 in the LLTHC 30 U T0 P5 series, providing versatility across various linear motion setups.

The carriage length is 100.4 mm and width is 60 mm. Dynamic load rating of 26.1 kN and static rating of 41.9 kN. Integrated side and inner seals protect against contaminants. Rails have dual reference sides for alignment precision.

Low friction construction minimizes wear and extends life. Four-thread mounting holes enable easy installation from the top side. Suitable for industrial, manufacturing, automation, and mechanical motion applications.

This product is manufactured in Taiwan, Province Of China, maintaining high quality standards. Explore the full range of Ewellix Makers in Motion Linear Guide Carriages and linear motion components available on EnvMart for your industrial machinery and spares needs.
