STMicroelectronics Through Hole 3-Pin TRIAC, 12A Rated Average On-State Current, 800V Peak Reverse Voltage BTA12-800CWRG
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 15.9mm |
| Length | 10.4mm |
| Model | BTA12-800CWRG |
| Mount Type | Through Hole |
| Configuration | Single |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 12A |
| Repetitive Peak Reverse Voltage VDRM | 800V |
| Surge Current Rating | 126A |
| Maximum Gate Trigger Current Igt | 35mA |
| Maximum Holding Current Ih | 35mA |
| Maximum Gate Trigger Voltage Vgt | 1.3V |
| Peak On-State Voltage | 1.55V |
| Repetitive Peak Off-State Current | 1mA |
| Peak Gate Power Dissipation | 1W |
Key Features
- The TRIAC supports a maximum gate trigger current of 35mA for efficient switching.
- The device operates reliably between -40°C and 125°C temperature range.
- It is housed in a TO-220 package, measuring 15.9mm in height and 10.4mm in length.
- The surge current rating is 126A, ensuring transient withstand capability.
- Maximum gate trigger voltage is 1.3V and holding current is 35mA.
- This single configuration TRIAC has a peak gate power dissipation of 1W.
- The repetitive peak off-state current is 1mA, minimizing leakage.
- Peak on-state voltage is rated at 1.55V, indicating low conduction losses.
Product Description
STMicroelectronics BTA12-800CWRG is a high-quality Through Hole TRIAC designed for industrial and electronic power control applications. This 3-pin discrete semiconductor device enables efficient AC switching and motor control in a variety of electrical and electronic circuits.
Rated for a 12A average on-state current and with a repetitive peak reverse voltage of 800V, the TRIAC is suitable for moderate power loads. The device supports a surge current rating of 126A, providing robustness against transient current spikes. The maximum gate trigger voltage of 1.3V and gate trigger current of 35mA facilitate precise gate control. Its maximum holding current is 35mA, ensuring stable latching operation.
The BTA12-800CWRG comes in a TO-220 through hole package measuring 15.9mm in height and 10.4mm in length, providing ease of integration on through-hole PCBs. Operating temperature ranges from -40°C to a maximum of 125°C, guaranteeing durability under industrial environmental conditions. The device has a peak on-state voltage of 1.55V and peak gate power dissipation of 1W.
The TRIAC supports precise control of resistive and inductive AC loads. It is suitable for motor speed controls, light dimmers, and static switching applications. Its rugged construction ensures reliable performance under demanding electrical conditions.
The device is RoHS compliant, facilitating eco-friendly circuit design. Wide operating temperature and voltage ranges make it adaptable to various industrial environments. The TO-220 package offers good heat dissipation characteristics.
Designed for easy mounting with three pins for secure PCB integration. Ideal for use in consumer, industrial, and HVAC applications requiring AC power control. This TRIAC is a reliable choice for engineers seeking robust semiconductor components for power electronics.
Explore more semiconductor products and TRIACs at EnvMart for your industrial, manufacturing, and electronic design needs.
Explore more products in our Electronics & Electricals Semiconductor category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The BTA12-800CWRG has a rated average on-state current of 12A.
It has a repetitive peak reverse voltage rating of 800V.
The surge current rating is 126A, providing robustness against transient current spikes.
The maximum gate trigger current is 35mA, which facilitates efficient switching.
It operates reliably between -40°C and 125°C.
The BTA12-800CWRG is housed in a TO-220 package, measuring 15.9mm in height and 10.4mm in length.
The peak on-state voltage is rated at 1.55V, indicating low conduction losses.
The maximum holding current is 35mA, ensuring stable latching operation.
This model supports through hole mounting, making it easy to integrate into PCBs.
The peak gate power dissipation is 1W.
The repetitive peak off-state current is 1mA, which minimizes leakage.
Yes, the BTA12-800CWRG is RoHS compliant, facilitating eco-friendly circuit design.
